CC61180 Series heavy duty manual horizontal lathe with 63 Tons Load Capacity

FOB Price

USD $300,500 - $921,587 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	Normal	Automatic Grade	Manual
Max. Swing Diameter	1800 mm	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	CC61180 heavy duty manual horizontal lathe
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	75kW
Dimension(LWH)	depends	Weight	depends
Certification	ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

CC61180 Series heavy duty manual horizontal lathe

Main Features

Such heavy duty lathe machines have following features:

1. Width of bed 2050mm with flat 4 guideways;

2. big spindle bore: 125mm;

3. for heavy and supper large workpiece: turning, threading and so on;

Main Technical Data

Specifications	Unit	Parameter
Swing over Bed	mm	1800
Max. swing over carriage	mm	1600
Max. length of work piece	mm	2000~20000
Width of bed With flat 4 guideways shown as Fig.1	mm	2050
Supporting weight between centers	T	63
Spindle taper bore	mm	125; 1:4
Spindle Speed	rpm	0.8 to 160, 2 steps
Bearings in spindle & tailstock		China
Angle of center		750
Dia. of chuck	mm	1600
Min. clamping diameter of chuck	mm	300
Torque of faceplate	KN.m	70
Type of turret		Frame support with tool row shown as Fig.2
Size of tool holder	mm	70x70
Travel of cross slide	mm	800
Travel of saddle	mm	9500
Travel of tool support	mm	350
Max.cutting force of tool post	KN	70
Feeding speed in X/Z-axis	mm/min	1~500
Rapid traverse in X/Z-axis	mm/min	4000
Servo motor for X/Z-axis	Nm	41
Travel of sleeve in tailstock	mm	300
Taper hole of tailstock sleeve	mm	125 1:4
Traverse speed of motorized tailstock	mm/min	2000
Traverse speed of quill in stailstock	mm/min	50
Power of main motor made in shanghai	kW	75 DC
Adjusting speed device for main motor		6 RA 70 of SIEMENS
Torque of carriage in X/Z-axis	Nm	27.3
Electrical power		380V/3—Ph /50Hz
Package and weight
Case I Headstock		2630×2000×2000mm 10T
Case 2 Stand of Head stock		2500×2160×1500mm 8.5T
Case 3 Front Part of Lathe Bed		7500×3300×2610mm 25T
Case 4Rear Part of Lathe Bed		7000×2800×1150mm 25T
Case 5 Main Motor		2700×1040×2620mm 2.8T
Case 6 Chuck		2350×2250×950mm 2.5T
Case 7 Electrical Cabinet		3000×900×2500mm 1.5T
Case 8 Case/Steady Rest		2800×1900×1200mm 1.8T

Factory Overview

kinds of colors for your choice/can be customized
