CW61180x8m 10 tons load heavy duty horizontal lathe made in china

FOB Price

USD $125,000 - $135,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	Normal	Automatic Grade	Manual
Max. Swing Diameter	1800mm	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	CW61180x8m heavy duty horizontal lathe
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	22kW
Dimension(LWH)	depends	Weight	depends
Certification	ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

CW61180x8m heavy duty horizontal lathe

Main Usage

1. I.D. & O.D. cylindrical turning,

2. end face turning,

3. I.D. & O.D. cone turning,

4. grooving,

5. threading;

Main Technical Data

Specifications	Unit	Parameter
Swing over bed	mm	1800
Swing over carriage	mm	1400
Distance between centers	mm	8000
Max. Cutting length	mm	7800
Width of bed	mm	1100
Support capacity between centers	T	10
Spindle bore	mm	100
Spindle nose		A2-15
Taper of spindle		Metric No. 140
Spindle speed	rpm	2 ~ 200 with 21 steps
Number of feeds and range		97
Max. travel of cross slide	mm	520
Travel of upper slide	mm	200
Travel of X-Axis	mm	880
Number and range of longitudinal	mm	0.064 ~ 12
Number and range of cross slide	mm	0.032 ~ 6
Number and range of top slide	mm	0.016 ~ 3
Rapid traverse	mm/min	Longitudinal 3740
Rapid cross slide	mm/min	1870
Rapid top slide	mm/min	935
No. and range of metric threads	mm	45 kinds 1~120
No. and range of inch threads	T. P. I.	42 kinds 30~1 / 4
No. and range of module threads		46 kinds 0.5~60
No. and range of diametric threads	D. P.	48 kinds , 60 ~ 0.5
Max. travel of tool post	mm	300
Tool shank section	mm	45 x 45
Taper in tailstock quill		Metric No. 80
Dia. Of tailstock sleeve	mm	200
Max. Travel of tailstock quill	mm	300
Power of main motor	kW	AC22
Power of rapid motor	kW	1.5
Power of pump motor	kW	0.55

Free Std Accessories

Optional Accessories

Name	Size	Price
Steady rest	RANGE 500 ~ 1100 mm
Follow rest.	50 ~220 mm
Support with two rollers	RANGE 850 ~ 1200mm
Digital display. Both directions	Length 5000 mm
	Length 6000 mm
	Length 8000 mm
Digital display. Both directions	Length 10000 mm
Taper turning device	LENGTH 800 mm
Motorized tailstock

Factory Overview

kinds of colors for your choice/can be customized
