Z3063 Hot-sale manual hydraulic radial drilling machine

FOB Price

US$ 13,109 - 13,509 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Drilling Speed	0.04~3.20mm/r	Place of Origin	Liaoning, China
Brand Name	DALIAN	Model Number	Z3063x20 hydraulic radial drilling machine
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	4kW
Dimension(LWH)	3080x1250x3245mm	Weight	7300kgs
Certification	ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

Z3063 radial drilling machine Technical Data

Product Introduction

Z3063 radial drilling machine has following features:

Major parts and critical parts are made of high strength cast and special steel material.
Heat treatment made by first-class equipment, ensuring durability.
Machining is made by means of specialized equipment, to ensure basic parts with superior quality.
Clamping for assemblies and speed-change of spindle are achieved by hydraulic power, and is sensitive and reliable. Multiple spindle speeds and feeds provide economic and high-efficiency machining.
Mechanical and electrical controls are centralized in the headstock, with convenient and rapid operation.
New painting technology and improved outward appearance reflects the specialty of machines.

Main Technical Data

Specifications	Unit	Z3063 radial drilling machine
Max. drilling diameter	mm	Φ63
Distance between spindle axis and column	mm	450~2000
Distance between spindle endandworking surface of base plate	mm	450~1650
Spindle travel	mm	400
Tapered of Spindle bore		Morse 5
Range of Spindle speeds	r/min	20~1600
Steps of Spindle speeds		16
Range of Spindle feeds	mm/r	0.04~3.20
Steps of Spindle feeds		16
Rocker rotary angle		±180°
Table size	mm	630×800
Travel spindle head	mm	1550
Power of main drive motor	kW	4
Weight (N.W/G.)	kg	7300/10600
Overall dimensions	mm	3080×1250×3245
