1xN(N≤16) Rack Optical Switch

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port ShenZhen
Payment TermsT/T L/C

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Glsun		Place of Origin	China
Model Number	SUN-FSW-1×N-A-B-C-D-E

Product Description

GLSUN 1xN(N≤16) Rack-mounted Optical Switch is a kind of functional device to control and switch optical route and can be manually selected from front panel or controlled via RS232 port, Ethernet port and auto-scanned on certain frequency.

In optical fiber transmission system, rack mount optical switch is used for multi-channel fiber monitoring, multi light source/ detector selection, and optical fiber path protection etc. Besides, 1xN rackmount fiber optc switch is also used in optical fiber test system for optical fiber and its component test, outdoor cable test and multi-spot optical sensors monitoring system.

Features

·Low Insertion Loss and Fast Switching
·SerialNet, High Reliability, High Stability
·LCD Display
·RS232 Control and Ethernet Remote Management

Applications

·FITL
·Automatic Measurement
·Optical Network Remote Monitoring
·Cable Monitoring and Maintaining system

Specifications

Parameters	Unit	SUN-FSW-1 × N- 1U (N≤16)
Insertion Loss 1, 2	dB	Typ:1.0 Max:1.2
Wavelength Range	nm	850±40 / 1300±40	1260 ~ 1650
Test Wavelength	nm	850 / 1300	1310 / 1550
Return Loss 1, 2	dB	SM ≥ 45 MM ≥ 30
Crosstalk 1	dB	≥ 55
PDL	dB	≤0.1
WDL	dB	≤0.25
Repeatability	dB	≤ ±0.05
Durability		≥ 10 Million
Optical Power	mW	≤500
Switching Time	ms	≤10 ( sequence switch time of adjacent channel)
Operating	℃	-5～+55
Storage Temperature	℃	-40~+80
Relative Humidity	%	5 ~ 95
Monitoring Port		RJ45, RS232
Power Supply	V	AC：100～240V（50/60Hz ） or DC：36～72V
Chassis Type	mm	1U L482.6 ×W250× H44
Remarks: Customization is available.

Optical Route

Ordering Information

SUN-FSW-1×N-A-B-C-D-E

Channel

Fiber Type

Test

Wavelength

Power Supply Mode

Connector

Chassis Type

≤ 16

SM: SM, 9/ 125

M5: MM, 50/ 125

M6: MM, 62.5/ 125

X: Others

850: 850nm

1310: 1310nm

1550: 1550nm

1310/ 1550:1310 / 1550nm

X:Others

AC: 100-240V

DC: 36-72V

AC/ DC: 100~240V /36~72V

AC/AC: Dual 100~240V

DC/DC: Dual 36~72V

X: Others

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

X: Others

1U:

L482.6 ×W250 × H44
