XFP-10G-ZR100-55 Cisco Compatible, 10GBASE-ZR/ZW XFP 1550nm 100km DOM LC SMF Fiber Optical Transceiver Module
USD $199 - $210
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- ShenZhen
- T/T L/C
You May Like
-
Cisco Compatible, DWDM-SFP10G-28.77 Optical Transceiver Module 10G DWDM SFP+ C61 1528.77nm 40km DOM LC SMF
-
SFP-1G-CWDM-1610-40 Cisco Compatible, 1000BASE-CWDM SFP 1610nm 40km DOM LC SMF Fiber Optical Transceiver Module
-
SFP-25G-SR Cisco Compatible, 25GBASE-SR SFP28 850nm 100m DDM LC MMF Fiber Optical Transceiver Module
-
SFP-25G-SR Cisco Compatible, 25GBASE-SR SFP28 850nm 100m DDM LC MMF Fiber Optical Transceiver Module
-
SFP-25G-CWDM Cisco Compatible, 25GBASE-CWDM SMF 1270nm 10km LC DOM SFP28 Fiber Optical Transceiver ModuleSFP-25G-CWDM Cisco Compatible, 25GBASE-CWDM SMF 1270nm 10km LC DOM SFP28 Fiber Optical Transceiver Module
-
SFP-25G-CWDM Cisco Compatible, 25GBASE-CWDM SMF 1370nm 10km LC DOM SFP28 Fiber Optical Transceiver Module
Product Details
| Brand Name | Glsun | Place of Origin | China | |
| Model Number | SUN-XFP-10G-ZR100-55-T02 |
Product Description
GLsun's XFP-10G-ZR100-55-T02 Small Form Factor 10Gb/s (XFP) transceivers comply with the current XFP Multi-Source Agreement (MSA) Specification. These 10g xfp zr transceiver modules are a true multi-protocol transceiver complying with 100km SONET OC-192 and SDH STM-64 per ITU-T G.959.1, and also support 10GBASE-ZR/ZW 100km 10-Gigabit Ethernet, 10-Gigabit Fibre Channel, and all related ITU-T G.709 FEC (OTN) data rates. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.
| Compatible | Cisco | Form Factor | XFP |
| Max Data Rate | 11.3Gbps | Wavelength | 1550nm |
| Max Cable Distance | 100km | Connector | Duplex LC |
| Transmitter Type | 1550nm EML | Extinction Ratio | 9dB |
| Media | SMF | Power Consumption | <3.5W |
| Power Supply Voltage | 3.3V | Operating Case Temperature | 0°C to +70°C (Commercial); -40°C t +85°C (Industrial) |
