Home > Products > VR Stepping motor > 3 Phase 86mm Size Series Length 150mm NEMA 34 Stepper Motor/ Stepper Motor Driver
3 Phase 86mm Size Series Length 150mm NEMA 34 Stepper Motor/ Stepper Motor Driver
- 30000 Piece / Pieces per Month
- SHANGHAI PORT, CHANGZHOU PORT
- T/T L/C PayPal
- 3 days
You May Like
-
3-Phase 220VAC 7A Digital Stepping Driver CF31022m
-
2 Phase 42HS Step 110mm NEMA42 Hybrid Step/Stepping/Stepper Motor for CNC Machine
-
2 Phase 86mm Size 10n. M 34HS13040/86sth130-6004 Length 130mm NEMA 34 Stepper Motor
-
4 Phase High Torque Low Vibration Square Type Stepping Motor 86bygh450b-01 Hybrid Stepper Motor
-
3 Phase 180-250VAC with Digital Display CF30822e Easy Servo Driver for Closed Loop Stepper Motor
-
86STH3P70-4003 hybrid stepper motor
Product Details
| Brand Name | THANK, CHANGFENG, CF | Place of Origin | China | |
| Model Number | CF30522M | Type | Variable Reluctance | |
| Phase | 3 | Certification | CE, ISO, ROHS |
Product Description
General Specifications:
Step Angle ----------------------------------------------------------------------------------------------------------------1.2° (full step)
Step Angle Accuracy --------------------------------------------------------------------------------------±5%(full step, no load)
Resistance Accuracy --------------------------------------------------------------------------------------------------------------±10%
Inductance Accuracy --------------------------------------------------------------------------------------------------------------±20%
Temperature Rise ----------------------------------------------------------------------80oC Max(rated current, 2 phases on)
Ambient Temperature Range ---------------------------------------------------------------------------------------- -20oC∽+50oC
Insulation Resistance --------------------------------------------------------------------------------------- 100MΩ Min. 500VDC
Dielectric Strength --------------------------------------------------------------------------------- 500VAC 50Hz 1mA 1 Minute
Insulation Class ------------------------------------------------------------------------------------------------------------------ B class
Electrical Specifications:
| Model | L Motor Length (mm) | Holding Torque (N.cm) Min. | Rated Current (A) | Phase Resistance (Ω) | Phase Inductance (mH) | Rotor Inertia (kg.cm2) | Lead Wire | Detent Torque (N.cm) Max. | Motor Weight (kg) |
| 34HT7040 | 70 | 250 | 4.0 | 0.7 | 9.3 | 1.1 | 3 | 12 | 2.1 |
| 34HT8040 | 80 | 300 | 4.0 | 0.9 | 12 | 1.23 | 3 | 15 | 2.3 |
| 34HT10040 | 100 | 500 | 4.0 | 1.3 | 16.2 | 2.7 | 3 | 20 | 3.3 |
| 34HT11840 | 118 | 600 | 4.0 | 1.60 | 16.5 | 3.3 | 3 | 30 | 3.7 |
| 34HT13040 | 130 | 750 | 4.0 | 1.95 | 17 | 4.0 | 3 | 35 | 4.0 |
| 34HT15040 | 150 | 900 | 4.0 | 2.35 | 19 | 5.0 | 3 | 45 | 5.5 |
*Shown in the table is the representative product. It can be customized according to the requirements of users.
