60ST-M Series PM Synchronous AC Servo Motor
- 3000 Set / Sets per Month
- Changzhou, Shanghai port
- T/T L/C
- 20 days
You May Like
Product Details
| Brand Name | THANK | Place of Origin | China | |
| Model Number | 60ST-M Series | Type | Servo Motor | |
| Output Power | 200W, 400W, 600W | Frequency | 3000r/min | |
| AC Voltage | 208-230 / 240 V | Certification | CE, ROHS | |
| Phase | Three-phase | Protect Feature | Waterproof |
Product Description
Sine Type PM Synchronous AC SERVO MOTOR
60ST-M SERIES
Electrical Specifications:
Specification Model | 60ST-M00630 | 60ST-M01330 | 60ST-M01930 | |
Rated Power(w) | 200 | 400 | 600 | |
Rated Torque(N.m) | 0.64 | 1.27 | 1.91 | |
Max Torque(N.m) | 1.91 | 3.82 | 5.73 | |
Rated speed(r/min) | 3000 | 3000 | 3000 | |
Max speed(r/min) | 3600 | 3600 | 3600 | |
Rated Current(A) | 1.27 | 2.5 | 3.73 | |
Max Current(A) | 3.69 | 7.33 | 11.0 | |
Rotor Inertia (kg.cm2) | 0.17 | 0.30 | 0.44 | |
Weight(kg) | 1.0 | 1.4 | 1.8 | |
Speed/Position Detector | Photoelectric Encoder: 2500p/rev | |||
Structure | Totally Enclosed Self-cooling（Protection ClassIP65） | |||
Working Voltage AC（V） | Three phases 220V-15%-+10% 50/60Hz(300V) | |||
Manner of Working | Continuous | |||
Insulation Class | F | |||
Ambient | Temperature | 0-40°C（Not Freeze），Keep：-25-70°C（Not Freeze） | ||
Humidity | Below 80%RH（Non-condensate） Keep：below90%RH（Non-condensate） | |||
Ambient Condition | Indoor (not directly affected by sunshine), away from corrosive gases, flammable | |||
Height | Elevation below 5000m | |||
Vibration | Axial：24.5m/S2 Radial：49 m /S2 | |||
Wiring Diagram：
Motor Line
No. | 1 | 2 | 3 | 4 |
Content | Red U | Yellow V | Blue W | GND |
Encoder Line
No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
Content | A+ | A- | B + | B- | Z+ | Z- | U+ | U- | V+ | V- | W+ | W- | VCC | GND | Shielding Line |
Dimensions(mm)：
60ST-M00630 | 60ST-M01330 | 60ST-M01930 | |
L | 96 | 121 | 146 |
*Shown in the table is the representative product, It can be customized according to the requirements of users.
Servo motor installation Notices:
1. When install/uninstall the coupling components to the shaft, please don’t hardly beat the shaft end to prevent the motor’s other encoder damaged;
2. Trying to make the coupling shaft’s concentricity to be best to extend the service life.
