Home > Products > Motor Driver > 3-Phase Stepping Motor Driver CF3065D
3-Phase Stepping Motor Driver CF3065D
- 3000 Set / Sets per Month
- SHANGHAI PORT
- T/T L/C
- 15 days
You May Like
Product Details
| Brand Name | THANK | Place of Origin | China | |
| Model Number | CF3065D | Motor Type | DC Motor |
Product Description
3-Phase Stepping Motor Driver CF3065D
Overview
CF3065D uses servo control principle technology. It has motor parameter adaptive function which ensures the best performance of the motor. The technology can significantly reduce the motor noise and improve stability. The maximum drive current is 5.8A and the highest positioning accuracy of 64 subdivisions can reach up to 12,800 steps / turn.
Key Features
1. 20 to 50VDC supply voltage
2. 3-phase Micro-stepping Drive
3. Suitable for 3-phase, 3 and 6 leads step motors, with NEMA size17 to 34
4. Output current selectable from 1.35~5.8A
5. Current reduction by 50% automatically, when motor standstill mode is enabled
6. Maximum steps for 12800 steps
7. Over Voltage, Coil to Coil and Coil to ground short circuit protection
8. Pulse Input Frequency 0～200KHz.
