High Efficiency Welding Column and Boom Manipulator for Vessel Longitudinal Seam Welding
Negotiable
/ Set
1 Set(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Pipe Rotating Automatic Welding Manipulators 2 * 2m for Circle Seam Welding
-
Automatic Pipe Welding Manipulators for Tanks and Vessels , VFD Control 120 - 1200 mm/min
-
Movable Welding Center Column And Boom for Pipe Cycle Welding Line
-
Automatic Welding Manipulator 4 * 4m Welding Working Station For Chemical Industry
-
High Precision Column & Boom Welding Manipulators With Submerged Arc Welding Power
-
Industrial Heavy Duty Column and Boom Welding Manipulators Boiler Cycle Welding Equipments
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | LH2020 |
Product Description
Certification:CE
High Efficiency Welding Manipulator LH2020 Press Vessel Longitudinal Seam Welding
Specifications:
1-trolley ,2-column revolve unit,3-column,4-flux feeding and recovery system ,5-guide saddle,6-elevating unit,7-boom,8-welding system
|
Technical parameter |
LHQ1010 |
LHQ2020 |
LHQ3030 |
LHQ4040 |
|
Elevating stroke mm |
1000 |
2000 |
3000 |
4000????????????????????????????????????????????????????????????????????? |
|
Retracting stroke mm |
1000 |
2000 |
3000 |
4000 |
|
Elevating speed mm/min |
1000 |
|||
|
Retracting speed mm/min |
120-1200(VFD) |
|||
|
Minimum distance between boom and track surface mm |
750(moving and revolve ) 680(fix and revolve) |
|||
|
Boom end maximum weight loading kg |
80 |
|||
|
Column revolving |
Manual revolving locked by screw |
|||
|
Trolley traveling |
Motorized movable ? |
|||
|
Inner span of trolley rail mm |
1000 |
Description:
1. Column and boom welding machine is the automatic welding equipment composed together with welding power.
Applications:
It can be used together with welding rotator or welding positioner, Widely used in industries as boiler, pressure vessel, petro-chemical machineryCompetitive Advantage:
This machine used for tank/vessel/pipe welding, circular seam and longitudinal seam welding. It can be formed a welding center working together with welding rotator or positioner etc; which is a ideal equipment for improving welding quality and efficiency.Contact Us
