Home > Products > Welding Positioner > Custom SHB Lifting Pipe Welding Revolve Table 600kg VFD Rotary Pipe Welding Equipment
Custom SHB Lifting Pipe Welding Revolve Table 600kg VFD Rotary Pipe Welding Equipment
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Tank / Vessel Auto Welding Positioners VFD Control Self Adjustable Table With Foot Switch
-
Automatic Pipe Welding Turning Table With T-Slots for Clamping Work-Piece 300KG
-
600Kg Boiler Pipe Welding Positioner Equipment 0.5rpm For Engineering Machinery
-
1.2T Pressure Vessel Pipe Rotary Welding Positioner With Worktable Revolving And Tilting Type
-
Standard 2 Ton Revolving Welding Rotary Table Metallurgical Type With 1.2m Worktable
-
High Precision Pipe Welding Positioners With Turning / Revolve Table HB30 3000KG
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | SHB06 |
Product Description
Certification:CE
Custom SHB Lifting Pipe Welding Positioners Loading 600kg , VFD Rotary Pipe Welding Equipment
Specifications:
|
Model |
SHB10 |
SHB20 |
SHB40 |
SHB60 |
SHB80 |
SHB100 |
|
|
Rated loading kg |
1000 |
2000 |
4000 |
6000 |
8000 |
100000 |
|
|
Max.Eccentricity distance mm |
150 |
150 |
150 |
150 |
200 |
200 |
|
|
Max gravity center distance mm |
350 |
350 |
350 |
350 |
400 |
400 |
|
|
Work-table dia.mm |
900 |
1200 |
1400 |
1500 |
1600 |
1800 |
|
|
Flip Angle |
0～135° |
0～135° |
0～120° |
0～120° |
0～120° |
0～120° |
|
|
Revolve speed rpm |
0.12～1.2 |
0.05～0.5 |
0.05～0.5 |
0.05～0.5 |
0.05～0.5 |
0.05～0.5 |
|
|
Tilt speed rpm |
0.29 |
0.25 |
0.2 |
0.2 |
0.15 |
0.15 |
|
|
Revote driving power kw |
1.1 |
1.1 |
2.2 |
2.2 |
2.2 |
3 |
|
|
Tilting driving power kw |
1.1 |
1.5 |
2.2 |
3 |
4 |
4 |
|
|
Out? size |
A mm |
1500 |
1780 |
2140 |
2760 |
3000 |
33330 |
|
B mm |
1210 |
1320 |
1500 |
1630 |
1850 |
2020 |
|
|
C mm |
1670 |
1800 |
2160 |
2600 |
2850 |
3140 |
|
|
E mm |
1100～1700 (p=150) |
1245～1845 (p=150) |
1350～1950 (p=150) |
1630～2430 (p=200) |
1790～2670 (p=220) |
1970～2930 (p=240) |
|
|
F mm |
775 |
1035 |
1360 |
1320 |
1630 |
1800 |
|
|
Rotation speed VPD controller |
|||||||
Description:
Welding positioner consists of frame, worktable, and tilting transmission device, Revolve transmission device, conduct device and electric control system, etc.Applications:
Frame is welding structure, which is welded into shape from beam and steel plate. The tilting bearing bases are installed on the both sides of wallboard. It has enough strength and rigidity.Competitive Advantage:
Worktable is steel welding structure. Using strengthen tendons to reinforce table and improve table rigidity. There are several concentric circle slots for positioning. And there are T-slots on the taContact Us
