High Accuracy CNC Flame Oxygen Cutting Machines For Steel Plate , CNC Cutting Equipment
- T/T L/C D/P D/A
- 7 days
You May Like
-
Multi-Head Strip Flame CNC Cutting Machine For Steel Structure , 9 Strip Torches
-
Automatic Gantry I / T / H Beam Production Line Auto Welding Machine , Gantry Welding Tools
-
Gantry Type Vertical Automatic Welding Machine for H Beam Line High Efficiency
-
H Beam Production Line Gantry Welding Machine / Equipment With Two Submerged Welder
-
Two Welding Arm Mobile Gantry Type Welding Machine For H Beam Welding Seam
-
Automatic Movable Gantry Welding Machine 18m Rail For H Beam Production Line
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | CNC-CG3500 |
Product Description
Certification:CE
Accuracy Cnc Flame Oxygen Cutting Machine For Steel Plate , CNC Cutting Equipment
Specification
|
Model |
Driving type |
Rail span(mm) |
Effective width(mm) |
Cutting thickness(mm) |
Vertical range of the cutting torch(mm) |
|
CNC-CG-3000 |
Single side |
3000 |
2200 |
6-150(Refer to the performance of the cutting nozzle) |
150 |
|
CNC-CG-3500 |
Single side |
3500 |
2700 |
150 |
|
|
CNC-CG-4000 |
Single side |
4000 |
3200 |
150 |
|
|
CNC-CG-5000 |
Double side |
5000 |
4200 |
150 |
|
|
CNC-CG-6000 |
Double side |
6000 |
5200 |
150 |
|
|
CNC-CG-7000 |
Double side |
7000 |
6200 |
150 |
|
|
CNC-CG-8000 |
Double side |
8000 |
7200 |
150 |
|
|
CNC-CG-9000 |
Double side |
9000 |
8200 |
150 |
|
|
CNC-CG-10000 |
Double side |
10000 |
9200 |
150 |
|
|
CNC-CG-11000 |
Double side |
11000 |
10200 |
150 |
|
|
CNC-CG-12000 |
Double side |
12000 |
11200 |
150 |
|
|
CNC-CG-13000 |
Double side |
13000 |
12200 |
150 |
Description:
Beam rail adopt complete rectangular pipe welded according to trapezoidal basket frame structure and through vibration aging treatment,
With strong anti-deformation and light inertia. Ensure non-deformation after long time using.??
Applications:
Servo driver: Panasonic servo motor with rotate speed, torque, position, tolerance three kinds of monitor mode and functions of malfunction auto alarm, prompt synchronized protection.
Strong spring realize the mesh between gear and rack for transmission, ensure the machine running precisio
Competitive Advantage:
The reducer box is adopt Germany NEUGART high precision reducer, with high transmission, and long time life span
Transmission: the transverse and longitudinal reducer is adopting Germany NEUGART high precision reducer cooperate import servo motor, ensure the stability of running and transmission precision.
