Self-Adjustable Pipe Welding Positioner Vessel Loading 8 Ton T-slots For Clamping
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
10000Kg Standard Pipe Welding Turntable Positioner For Petro-Chemical Industry
-
High Frequency welding Turning Table With Working Table / Pedestal Schneider Electric
-
Engineering Pipe Boiler Welding Positioner Turntable With Overturning Device / Working Table
-
High Frequency Pipe Welding Positioners 30 Ton Head Tail Welding Turn Table
-
Pipe or Tank Welding Turning Table / Turning Revolve Table Self Adjustable Type
-
Multi Function 9 + 2 Practical Flame CNC Cutting Machine Single Drive For Aluminum / Carbon Steel
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | HB80 |
Product Description
Certification:CE
Self - Adjustable Pipe Welding Positioners Vessel Loading 8Ton, T-slots For Clamping
Specifications:
|
No. |
Item |
||||||
|
1 |
Model |
ZHB-03 |
ZHB-06 |
ZHB-12 |
ZHB-30 |
ZHB-50 |
ZHB-100 |
|
2 |
Rated load (kg) |
300 |
600 |
1200 |
3000 |
5000 |
10000 |
|
3 |
Max eccentric distance (mm) |
100 |
150 |
200 |
200 |
200 |
200 |
|
4 |
Max distance of the gravity center (mm) |
150 |
200 |
250 |
300 |
300 |
400 |
|
5 |
Worktable φ D (mm) |
600 |
1000 |
1200 |
1400 |
1500 |
1800 |
|
6 |
Tilting angle(°) |
0-90 |
0-90 |
0-120 |
0-120 |
0-120 |
0-120 |
|
7 |
Rotating speed (rpm) |
0.15-1.5 |
0.11-1.1 |
0.11-1.1 |
0.11-1.1 |
0.05-0.5 |
0.03-0.3 |
|
Speed control |
VFD for rotation speed |
||||||
|
8 |
Tilting speed (rpm) |
manual |
1.1 |
0.4 |
0.23 |
0.2 |
0.14 |
|
9 |
Rotating motor power(kW) |
0.18 |
0.55 |
0.75 |
1.5 |
2.2 |
3 |
|
10 |
Tilting motor power(kW) |
/ |
0.75 |
1.5 |
2.2 |
3 |
4 |
|
11 |
Worktable T slot qty |
4 |
4 |
6 |
6 |
6 |
6 |
Description:
Worktable is steel welding structure. Using strengthen tendons to reinforce table and improve table rigidity. There are several concentric circle slots for positioning. And there are T-slots on the table surface for clamping work piece.Applications:
Large used for Petroleum and Power etc industry used?to?weld,polish?and?assemble?the?cylinderCompetitive Advantage:
Wind power fabrication Chemical & fuel storage tank fabrication Any heavy cylindrical jobContact Us
