Rubber Roller Steel Pipe Welding Turning Rolls , Tank Welding Rotator 150000kg

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	H-WELDING		Place of Origin	China
Model Number	XHGK150

Delivery Time:15 working days after received your payment
Certification:CE

Rubber Roller HGK150 Welding Turning Bed Used For Chemical Industry Pipe seam Welding

Specifications:

Model	XHGK-2	XHGK-5	XHGK-10	XHGK-20	XHGK-40	XHGK-60
Max. loading (T)	2	5	10	20	40	60
Vessel diameter (mm)	150-2000	250-2300	320-2800	500-3500	600-4200	750-4500
PU roller dia.&width(mm)	200*80	250*100	300*120	350*150	400*180	451802
Metal roller dia.&width(mm)	Option
Linear speed mm/min	100-1000
Speed control way	VFD (stepless variable frequency speed control)
Motor power (KW)	2*0.18	2*0.37	2*0.55	2*1.1	2*1.5	2*2.2
Roller center distance adjust way	Bolt-adjustable?
One set inc.	One power and one idle
?	?	?	?	?	?	?	?	?

Note: For 2-100T roller is steel and rubber combination roller.For 100-500T roller is made of whole steel roller or imported rubber.

Description:

Used for tank or taper Circle Seam Welding Loading pipe and rotary it with a VFD speed control Making work-piece at a optimum welding position

Applications:

Any heavy cylindrical job Anti creep function; Hydraulic lifting for?fit up pipes;

Competitive Advantage:

It can be designed as movable type CE approved The center distance adjustable by bolt
