80Ton Lead-Screw VFD Control Welding Turning Rolls / Rotators For Cylinder Cycle Seam
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hydraulic Fit Up Welding Turning Bed Tank Rotator For Chemical Industry Pipe Seam Welding
-
Marine Building Welding Rotary Table / Welding Turntable Round or Custom Shape
-
Head / Tail Welding Equipment Welding Positioner for Tilting and Rotation 600kg Load
-
Hydraulic Double Column Rotary Welding Table , Tank Turning Table for Welding Line Machinery
-
Lifting Height Adjustable Pipe Welding Rotary Positioner High Precision 300kg Manual Revolve
-
Height Adjusting Automated Pipe Welding Positioner Turntable For Vessel Loading And Machining
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | CHGK100 |
Product Description
Certification:CE
Anti Drift Lead-Screw Welding Turning Roll 100Ton In Welding center For Vessel Seam Welding
Specifications:
|
Manual Adjust Welding Turning Roller HGK40 Fit Up And Assembly For Shell Model |
CHGK-2 |
CHGK-5 |
CHGK-10 |
CHGK-20 |
CHGK-40 |
CHGK-60 |
||
|
Max. loading (T) |
2 |
5 |
10 |
20 |
40 |
60 |
||
|
Vessel diameter (mm) |
150-2000 |
250-2300 |
320-2800 |
500-3500 |
600-4200 |
750-4500 |
||
|
PU roller dia.&width(mm) |
200*80 |
250*120 |
300*140 |
350*150 |
400*180 |
45*180*2 |
||
|
Metal roller dia.&width(mm) |
Option |
|||||||
|
Linear speed mm/min |
100-1000 |
|||||||
|
Speed control way |
VFD (stepless variable frequency speed control) |
|||||||
|
Motor power (KW) |
2*0.18 |
2*0.37 |
2*0.55 |
2*1.1 |
2*1.5 |
2*2.2 |
||
|
Roller center distance adjust way |
Lead screw adjustable |
|||||||
|
One set inc. |
One power and one idle |
|||||||
| ? | ? | ? | ? | ? | ? | ? | ? | ? |
Note: For 2-100T roller is steel and rubber combination roller.For 100-500T roller is made of whole steel roller or imported rubber.
Description:
Make the vessel rotary automatically Consist of base, driving roller and idle roller, rack, transmission device, the power gear drive, etc Loading pipe and rotary it with a VFD speed controlApplications:
Wind power fabrication Chemical & fuel storage tank fabrication Any heavy cylindrical jobCompetitive Advantage:
Chemical & fuel storage tank fabrication Any heavy cylindrical jobContact Us
