Linkage Control Welding Column and Boom Light Duty Type For Welding Center
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Motorized Rotation Welding Working Station Manipulator for Pipe / Tank Welding Equipment
-
Heavy Duty Welding Manipulators Column Boom For Pressure Vessel Welding
-
Weld Column And Boom Welding Manipulators 7 * 7m Stationary Type With Flux And Recycle Unit
-
Wind Tower Assembly And Fit Up Welding Turning Rolls / Turning Bed Rotator with PU Roller
-
80 Ton Full-Automatic VFD Control Pipe Welding Rotators For Cylinder Seam Welding
-
Self-adjustable Welding Turning Rolls / 100Ton Self-aligned Welding Roller for Pipe Welding
Product Details
| Brand Name | H-WELDING | Place of Origin | China | |
| Model Number | LH6060 |
Product Description
Certification:CE
6000mm * 6000mm Welding Column & boom Linkage Control For Welding Center
Specifications:
1-trolley ,2-column revolve unit,3-column,4-flux feeding and recovery system ,5-guide saddle,6-elevating unit,7-boom,8-welding system
|
Technical parameter |
LHC5050 |
LHC6060 |
LHC7070 |
LHC8080 |
|
Elevating stroke mm |
5000 |
6000 |
7000 |
8000 |
|
Retracting stroke mm |
5000 |
6000 |
7000 |
8000 |
|
Elevating speed mm/min |
1650 |
|||
|
Retracting speed mm/min |
50-1000 |
|||
|
Minimum distance between boom and track surface mm |
1290 movable with revolve |
1210 stationary with revolve |
||
|
Boom end maximum weight loading kg |
400 |
500 |
600 |
|
|
Column revolving |
Angle |
＋180o |
||
|
Speed rpm |
0.17rpm/or by manual |
|||
|
Trolley traveling speed mm/min |
2000 |
|||
|
Inner span of trolley rail mm |
2500 |
Description:
Column top is the boom elevation unit, consist of AC brake motor, worm reducer and chain sprocket couple etc which can realize boom elevating to suitable position. The brake motor is not only ensuring pinpoint but also avoiding shocking. There is a rachet anti-dropping unit. If the chain break off which can prevent boom dropping, safe and reliable.Applications:
Energy Wind Power Wind Tower PowerCompetitive Advantage:
The boom connects with column by guide holder, which realizes not only elevating in vertical but also retracting in horizontal. There is motorized cross slider at the end of boom together with welding unit, and wire spool is equipped at the other end of boom. The wire connects to welding gun via guide pipe along with boom.Contact Us
