180000 RPM Precision Machining High Frequency Spindles CNC Multi Spindle

Compatible WWD1686 180,000RPM KL180B ?PCB Drilling Spindle

Quick Detail:

PRODUCT DESCRIPTION

KL180B ?high frequency?spindle replace for WW D1686-10; D1686-XX Full Range from 20,000 to 180,000 rpm, air bearing type in long life, spindle weight 3.6kg with COLLET size ?1/8” and body size ? 61.9

Max power:0.75KW

Air Pressure: 6.0 kgf/cm2

Coolant:Water oil

Fixed voltage:210V

Fixed current:4A

FREQUENCY (HZ): 334-3075

Competitive Advantage:

Low Static

Low Dynamic RUN OUT

Stable character and long life

Suitable for precision drilling

Air bearing type offer Greater Precision, High Speed , Increased Tool Life, Improved Surface Finish, Long Bearing Life, Low Thermal Growth, Lack of Maintenance, Large Load Capacity , Reduced Vibration , Cleanliness.?

APPLICATION :

PRINT CIRCUIT BOARD PRECISION DRILLING

HOLE RANGE: ?6.35mm-0.05mm

MACHINE REFERENCE:KLINGINBERG PLURITEC ；HITACHI ；LENZ ；ANDERSON ….

SPECIFICATION:

????????????????????????????? SPINDLE OUTLINE DRAWING

Why choose KLKJ?

With nearly 15 years technology in spindle maintenance, 10 years success experience for spindles parts production, and 9 years spindle R&D, KLKJ succeed in offer air bearing spindle up to 200krpm.

All spindles at the KLKJ are fully checked and tested using stringent quality control procedures. KLKJ ensures every repaired spindle passes the following points to make it in long life and stable character:
