WESTWIND WWD1822 200000RPM Water Cooled CNC Spindle Motor For HITACHI / LENZ Machine

Compatible WESTWIND WWD1822 200,000RPM KL200L Air Bearing Spindle PCB PRECISION DRILLING?

Quick Detail:

PRODUCT DESCRIPTION

KL200L higher speed rotation and higher accuracy spindle replace for WESTWIND WW D1822 Full Range from 20,000 to 200,000 rpm, air bearing type in long life, spindle weight ?4.3kg with COLLET size 1/8” and body size ? 61.9.\'

Max power:0.9KW

Air Pressure: 6.0 -6.5kgf/cm2

Coolant:Water oil

Fixed voltage:215V

Fixed current:4A

FREQUENCY (HZ): 334-3570

PTC ?Or NTC SENSOR For choose (Data pl. inquiry)

Competitive Advantage:

Low Static

Low Dynamic RUN OUT

Stable character and long life

Power and very low heat generation

ATC feeder / ATC tool change for micromachining

KLKJ Advantage

The higher spindle speeds available allow for increased productivity whilst ensuring that accuracy and repeatability is maintained.
Advanced analysis and detailed design has created a spindle with exceptional reliability and increased efficiency.

APPLICATION :

PRINT CIRCUIT BOARD PRECISION DRILLING

HOLE RANGE: ?6.35mm-0.05mm

MACHINE REFERENCE: KLINGINBERG PLURITEC ；HITACHI ；LENZ ；ANDERSON;SCHMOLL ….

SPECIFICATION:

???????????????????????????????? Spindle?outline?drawing?

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?Spindle Quality and Service ?Comment from customer
