12A Electrical AC Magnetic Contactor / motor contactor for short load Protection

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	VECAS		Place of Origin	China
Model Number	HC1-K

Product Description

Delivery Time:WITHIN 30DAYS AFTER L/C OR 30% DEPOSIT RECEIVED
Certification:CE

12A Electrical AC Magnetic Contactor / motor contactor for short load Protection

Application

HC1-K series be used in the circuit 50Hz/60Hz, working voltage up to 690V,current to 12A, AC Motor, long distance connect & break circuit, frequency? starting, as well. It can also be fitted with contactor blocks, or sutible thermal relay
to protect over short load.

Speci?carions

HC1-K06	HC1-K09	Type			HC1-K12
6	9	Rated current at AC-3 (A)			12
5	7.5	Rated working current (le) (A)			10
16	20	Conventional thermal current (th) A			20
1.5	2.2	AC-3 use group control power KW	220V		3
2.2	4		380/415V		5
3	4		440/500V		5
3	4		660V		5
380?? 660	380?? 660	Rated working voltage (Ue) V			380?? 660
690	690	Rated insulation voltage (Ui) V			690
0.5×106	0.5×106	AC-3 (6le le)	Electrical life (times)		0.5×106
1200	1200		Operation frequency h?-1		1200
10×104	10×104	AC-4 (6le le)	Electrical life (times)		10×104
300	300		Operation frequency h?-1		300
3×106	3×106	Mechanical life			3×106
6A	6A	Auxiliary contact	Conventional thermal current		6A
0.5×106	0.5×106		Electrical life (times)	AC-15 (360VA)	0.5×106
