0.3-- 4.0mm CNC Small Hole Drilling EDM Machine TG703F-2
- Shenzhen
- T/T
You May Like
-
B1 series drilling machine/Z4120B1
-
Industrial type bench drilling machine/Z4125D
-
SZ-20C Series Swiss CNC Precision Automatic Bar Lathe machine for sale
-
Universal Knee-Type Milling Machine X6142
-
ZX6350D universal drilling and milling machine with high quality
-
electric discharge edm wire cutting/cnc wire cut machine dk7740
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Yunnan, China | Brand Name | XIASHI | |
| Model Number | TG703 | Voltage | 380V | |
| Power(W) | 1.2kw+ | Dimension(L*W*H) | 850*750*1850mm | |
| Weight | 500KG | Certification | CE,ISO | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
TG703F-2 high - speed EDM Drilling Machine
Introduction
TG703 Series EDM drilling machine using the latest German technology.
Using the German circuit board design and the rotating head connector and imported water pump, greatly enhance the market competitiveness of products.
Processing super hard metal or hardening workpiece after heat treatment.
Processing diameter 0.3--4.0, high precision drilling, drilling depth of up to 100 times the diameter of the electrode.
Can process super-hard metal or hardening workpiece after heat treatment.
Can process perforation of line cutting.
Remove the screw tap cutting.
Can process plane of irregular or spherical.
Feature
1.Can process stainless steel, hardened steel, cemented carbide, copper, aluminum and other conductive materials.
2.Using the German circuit board design and the rotating head connector and imported pumps.
3.Can process diameter of 0.3-4.0mm
4.Processing speed can reach 30-60mm per minute.
5.Can penetrate directly from the slope, surface.
6.Directly Using water as the working fluid.
7.Latest digital high-frequency circuits.
Technical parameter
Clamping electrode diameter 0.3-- 4.0mm |
Highest placed workpiece height 400mm |
Servo travel 400mm |
Dimension of workingtable 400x300mm |
X--Yaxis travel 370x270mm |
Overall dimensions 850x750x1850 |
Machine weight 500Kg |
Motor 3.0Kw |
working fluid purified water |
Max.loading capacity 200Kg |
|
Picture details
