Home > Products > Mini Speaker Boxes Implanted > Micro Speaker Box Implanted P/N YDT34114N-R001B08
Micro Speaker Box Implanted P/N YDT34114N-R001B08
Negotiable
/ Piece
2000 Pieces(Min.Order)
- 500000 Piece / Pieces per Month
- Shenzhen
- T/T
You May Like
-
Micro Speaker Box Implanted P/N YDT1425N-R018B08
-
Micro Speaker P/N YDT2828N-R02F4 (W28.0*L28.0*H10.3) with concave membrane for multimedia
-
Micro Speaker P/N YDT4646N-RB04F4 (W46.0*L46.0*H22.0) with concave membrane for multimedia
-
Micro Speaker P/N YDT3232N-RB07F4 (W32.0*L32.0*H16.0) with concave membrane for multimedia
-
Micro Speaker P/N YDT3434N-RB10F8 (W34.1*L34.1*H14.6) with concave membrane for multimedia
-
Micro Speaker P/N YD40A-RB36F4-R1 (D40.0*H19.5) with concave membrane for multimedia
Product Details
| Brand Name | WBN | Model Number | YDT34114N-R001B08 | |
| Use | Karaoke Player, Other | |||
| Place of Origin | Guangdong, China |
Product Description
Specifications
With completed resonant box, leadwires and connector for devices with existing amplifier
SPECIFICATION DATA SHEET | |||
ITEM / DESCRIPTION | SPECIFICATION | REMARKS | |
| 1. Speaker with Resonant Box | Dimension: W34*L114 | ||
1.1 Speaker Drives | Mini Oblong Speaker P/N YT14N25-C12 | ||
1.2 Impedance | 8Ω± 1.2 | @ 600Hz | |
1.3 Power Rated/Max | 8W | @ 8V | |
1.4 Sound Pressure Level | 77.5±3dB | @ 1 m (At 800,1000, 1200, 1500 ,Hz Average) | |
1.5 Characteristic Sensitivity | |||
1.6 Frequency Resonant fo | 180± 36Hz | @ 1.0V | |
1.7 Frequency Range | FO ~ 20KHz (SPL-15dB) | @ 2.83V | |
| 2. Connecting Solution | 1 pcs of box connected with Lead Wires | ||
2.1 Lead Wires | UL10368 22AWG/black wire with 94mm/white with 33mm | Optional | |
2.2 Terminal | Optional | ||
| 4. Weight | 154±20% g | ||
| 5. RoHs Compliant | Yes | ||
| 6. Packing Details | |||
| 7. FEATURES | Slim with high power rated | ||
