Vibration Meter AR63B (Detached probe type) vibration tester vibration gauge
- T/T Credit Card PayPal
You May Like
-
Vibration Meter AR63A (portable type) vibration tester vibration gauge
-
Vibration Meter VM-6320 vibration tester vibration gauge
-
Vibration Meter VM-6310 vibration tester vibration gauge
-
Vibration Meter VM-6360 vibration tester vibration gauge
-
Vibration Meter VM-6320,Vibration tester,digital Vibration gauge
-
Vibration Meter VM-6320, vibration tester, vibration meters, vibration gauge
Product Details
| Place of Origin | Guangdong, China | Brand Name | Graigar | |
| Model Number | AR63B |
Product Description
Specifications
vibration meter, vibration gauge, vibration tester AR63BVibration Meter AR63B (Detached probe type)
Vibration meter is used for measuring periodic motion, to check the imbalance and deflecting of moving machinery. Specifically designed for present measuring various mechanical vibration. So as to provide the data for the quality control, run time and equipment upkeep.
Measuring Range:
Acceleration: 0.1-199.m/S2 peak(rms*v2)
Velosity: 0.1-1999.9mms rms
Displacement: 0.001-1.999mm p-p(rms*2v2)
Accuracy: +/-5%+/-2digits
Frequency Response:
Acceleration: 10Hz-1KHz(LO) 1KHz-15KHz(HI)
Velosity/Displacement: 10Hz-1KHz
Data Output: AC Output 2V Peak,Load
Test Mode: Acceleration/Velocity/Displacement
Sampling Rate: 1S
Low Battery Indication
Auto Shut Off
Detached unit design and easy to use
Maximum value hold function
Environment temperature display function
Accessory with USB and computer software can connect to computer
Power: 9V Battery (6F22)
Battery Life: 25 hours Continuous Operation
Products net weight: 137g / 0.3lb
Products size: 150x70x30mm (5.9x2.76x1.18 inch)
