20 - 30 Degree 10mm Round Dip Power Led Diode
- Shenzhen
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | WEJ | |
| Model Number | WEJ00BGC-DQ5 | Package Type | Surface Mount | |
| Max. Forward Voltage | 3.0-3.4V | Max. Forward Current | 30mA |
Product Description
Products Details
Part No.
| Emitted Color
| Resin color
| Viewing Angle(1) 2θ1/2 |
WEJ00BGC-DQ5 | Green | Water clear | 20 |
Parameter | Symbol | Value | Unit |
Power dissipation | Pd | 72 | mW |
DC Forward Current | If | 30 | mA |
Peak Forward Current(1) | Ifp | 100 | mA |
Reverse Voltage | Vr | 5 | V |
Electro-Static-Discharge(HBM) | ESD | 2000 | V |
Operating Temperature | Topr | -25to+85 | ℃ |
Storage Temperature | Tstg | -40to+100 | ℃ |
Lead Solder Temperature(2) | Tsol | 260 for 5sec | ℃ |
Parameter | Symbol | Condition | Value | Unit | ||
Min. | Typ. | Max. | ||||
Forward voltage | Vf | If=20mA | --- | 2.1 | 2.4 | V |
Luminous intensity | Iv | If=20mA | 2500 | 5000 | --- | mcd |
Dominant wavelength | λd | If=20mA | 620 | 625 | 635 | nm |
Peak wavelength | λp | If=20mA | --- | 645 | --- | nm |
Reverse current | Ir | Vr=5V | --- | --- | 10 | μA |
Feature
*Low power consumption
*Long life-solid state reliability
*Available on tape and reel
*RoHS compliant
Shippment:
DHL TNT TM Registered Airmail or By sea
Shipped 7 days after payment
Payment:
T/T PAYPAL or others ways
Our services:
- 2 years warranty
- Professional sales teams
- Free sample is available, but customers need to pay the freight
- We devolope, we design, we manufacture
- We get CE/ROHS
Certifications:
Company information:
WEJ Lighting Technology Co,Ltd, set up jointly by WEJ Electronic Co,Ltd,mainly focuses on R&D and production of LED lighting products. All our products have got the certification of CE, FCC ,PSE,UL and all our production process are completely guided by ROHS and REACH directive.
