Product Details
| Model Number | WEJ324RD-EU1 | Chip Material | AlGaInP | |
| Emitting Color | Red | Luminous Intensity | 1300mcd | |
| Power | 0.06W | Operating Temperature(℃) | -25, 85 | |
| Storage Temperature(℃) | -40, 100 | Place of Origin | Guangdong, China | |
| Brand Name | WEJ 1.5V 3mm led diode | Certification | CE |
Product Description
Through hole package red diffused 1.5V 3mm led diode
Electrical characteristics data sheet
Selection Guide
| Part No. | Emitted Color | Resin color | Viewing Angle |
| WEJ324RD-EU1 | Red | Red diffused | 80 degree |
Absolute Maximum Ratings at Ta=25 ℃
| Parameter | Symbol | Value | Unit |
| Power dissipation | Pd | 72 | mW |
| DC Forward Current | If | 30 | mA |
| Peak Forward Current | Ifp | 100 | mA |
| Reverse Voltage | Vr | 5 | V |
| Electro-Static-Discharge(HBM) | ESD | 2000 | V |
| Operating Temperature | Topr | -25 to +85 | ℃ |
| Storage Temperature | Tstg | -40 to +100 | ℃ |
| Lead Solder Temprature | Tsol | 260 for 5sec | ℃ |
Notes:
1. 1/10 duty cycle, 0.1 ms pulse width;
2. 2mm below package base.
Electrical/Optical Characteristics Ta=25 ℃
| Parameter | Symbol | Conditin | Value | Unit | ||
| Min | Typ | Max | ||||
| Forward voltage | Vf | If=20mA | --- | 2.0 | 2.4 | V |
| Luminous intensity | Iv | If=20mA | 1000 | 1300 | --- | mcd |
| Dominant wavelength | λd | If=20mA | 620 | 621 | 630 | nm |
| Peak wavelength | λp | If=20mA | --- | 645 | --- | nm |
| Reverse current | Ir | Vr=5V | --- | --- | 10 | A |
Notes:
1. Forward Voltage: ±0.1V
2. Wavelength: ±1.5nm
3. Luminous Intensity: ±10%
Package outline dimensions of 3mm led diode:
Notes:
1. All dimensions are in milllimeters;
2. Tolerace is ±0.25mm unless otherwise noted;
3. Lead spacing is measured where the leads emerge from the package;
4. Specifications are subject to change without notice.
| Product | Quantity/bag | Quantity/carton | GW/CTN | Carton Size |
| 1.5V 3mm LED diode | 1000pcs | 60000pcs | 11.3kg | 56*29*31cm |
Shipping:
*By Air: From Shenzhen or HK airport.
*By Sea: From Shenzhen or HK port.
*By Express door to door: DHL, TNT, UPS, FedEx, EMS ect.
1. Experienced R&D team
2. Professional production process
3. Free samples support
4. Short lead time
5. Customized will be welcome
6. Small order acceptable
WEJ Overseas sales team:
WEJ Industry park:
Office:
WEJ Porduction machine
Production Machinery
| Machine Name | Brand&Model No. | Quatity | Number of year (s) used | Condition |
| Solid Crystal Machine | ASM AD820 | 8 | 4 | Acceptable |
| Wire Bonder | Eagle 60V | 8 | 4 | Acceptable |
| Oven | XinZhou | 15 | 6 | Acceptable |
| Automatic Sealing Machine | HWTB20K | 1 | 4 | Acceptable |
| Automatic Dispener | SHOTMASTER300 | 3 | 4 | Acceptable |
| LED Lamp Splitter | HWINL 1800,H565 | 3 | 5 | Acceptable |
| Reflow Soldering Machine | V-FC8800-LF | 1 | 4 | Acceptable |
| Automatic Braiding Machine | H635 | 1 | 1 | Acceptable |
| Automatic Glue Machine | Speed3000 | 1 | 1 | Acceptable |
Testing Machinery
| Machine Name | Brand & Model No. | Quantity | Number of Year(s) Used | Condition |
| LED Intergrating Sphere | EVERFINE | 2 | 1 | Acceptable |
| Video Measuring System | JIVMS-1510 | 1 | 2 | Acceptable |
| Braid Tester | No Information | 1 | 7 | Acceptable |
| Transistor Curve Tracer | QT2 | 1 | 7 | Acceptable |
| Voltage Regular Tube Tester | SZN6000N | 4 | 7 | Acceptable |
| Thermal Shock Chamber | TS-42A | 1 | 3 | Acceptable |
| Temperature and Humidity Chamber | TH-80B | 1 | 3 | Acceptable |
| Hig Temperature Aging Tester | XINZHO | 1 | 3 | Acceptable |
| High Voltage Aging Line | No Information | 1 | 3 | Acceptable |
Factory information
| Factory Size (ters): | 3,000-5,000 square meters |
| Factory Location | 1/F and 3/F, Building 21, 6th Industrial Area, Yulv Community, Guangming New District, Shenzhen City, Guangdong China. |
| Number of Production line staff | More than 100 persons |
| Number of R&D Staff | 15-20 persons |
| Number of QC Staff | 11-20 persons |
| Management Certification | ISO9001 ISO14001 |
| Contract Manufacturing | OEM Service Offered, Design service offered |
