Home > Products > Color Steel Roll Forming Machine > Full Automatic Tile Making Machine Price Tile Machine Tile Making Machine
Full Automatic Tile Making Machine Price Tile Machine Tile Making Machine
- 30 Set / Sets per Month
- Tianjin new port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Steel | Use | Roof | |
| Production Capacity | 10-12m/min | Place of Origin | Hebei, China | |
| Brand Name | Zhongtuo | Model Number | roll forming machine | |
| Power(W) | 5.5 kw | Voltage | 380V or as required | |
| Dimension(L*W*H) | 8.5*1.65*1.5m | Weight | 4.5T | |
| Certification | ISO9001 and CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Full Automatic Floor Tile Making Machine Price Tile Machine Tile Making Machine
1.Processing technique and deployment
Full Automatic Floor Tile Making Machine Price Tile Machine Tile Making Machine by the uncoiling,feeding, leveling,roll forming,shearing, production, Production of color plate appearance of smooth beautiful paint pattern uniform, high strength, durable, widely used in industrial and civil buildings, such as factories, warehouses, stadiums, exhibition halls, theaters and other room surfaces and walls.
Flow chart : Decoiler-- Roll Forming--PLC System—Hydraulic System –Pressing --Cutting —Output Table
No. | Name | Unit | Qty |
1 | Decoiler | set | 1 |
2 | Main Machine for roll forming | set | 1 |
3 | Control System(PLC) | set | 1 |
4 | Pressing System | set | 1 |
5 | Cutting System | set | 1 |
6 | Output Table | set | 1 |
| Tile Making Machine Description | Introduction |
| Working efficiency | 8-12m/min |
| Thickness of Material | 0.3--0.8mm (can be changed according to customers need) |
| Width of material | 914mm;940mm;1000mm;1200mm;1220mm;1250mm According to customers need |
| Control system | PLC(The brand can be choose) |
| Uncoiler system | 5Ton Manual Operation(1250mm width) |
| Forming by rolling | 13 rows (According to the machine design) |
| Roller material | GCR15 Aluminium processing after quenchin HRC58-62°C,Chrome plated |
| Shaft and the diameter of axle | 45#Aluminium-processing ,diameter of axle=80mm |
| Main part power | 5.5kw |
| Hydraulic motor power | 4kw |
| Hydraulic pressure | 12Mpa |
| Scissor material | Cr12Mov, herd steel HRC 58-62°C |
| length tolerance | ±1.5mm |
| voltage | 380V, 50HZ,3 phase (adjustable by customer needs) |
| Frame form | Middle plate |
| Driving Method | Chain |
| Color | Yellow and blue(adjustable) |
| Size | length*Width*Height - 8.2*1.65*1.5m |
| weight | about 5.0T |
| Package | Nude package in 1*20GP container |
| Delivery date | 30 working days |
| Payment Method | 30% T/T in advance and balance 70% after inspection confirmation before shipment. |
If you have your own drawing, please send it to us, we can design the machine, depend on your drawing. | |
