Most Popular Double Layer for Corrugated and Trapezoidal Roof Tile Roll Forming Machine
- 30 Set / Sets per Month
- Tianjin new port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
840 high quality color steel roll forming machine
-
corrugated sheet making machine, corrugated metal sheet rolling machine
-
corrugated aluminum roofing sheet forming machine
-
corrugated iron sheet machinery, corrugated metal sheet rolling machine
-
double layer making machine
-
PPGI trapezoidal and trapezoidal double layer roll forming machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Steel | Use | Roof | |
| Production Capacity | 10-12m/min | Place of Origin | Hebei, China | |
| Brand Name | Zhongtuo | Model Number | corrugated sheet metal roof making machine | |
| Power(W) | 5.5 kw | Voltage | 380V or as required | |
| Dimension(L*W*H) | 8.5*1.65*1.5m | Weight | 6.5T | |
| Certification | ISO9001 and CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Most Popular Double Layer for Corrugated and Trapezoidal Roof Tile Roll Forming Machine
Materials:
Processing material: colored steel plate, galvanized plate, or aluminum plate
Material thickness: 0.3- 0.8 mm (or as your request)
Coil width:1200 mm(or as your request)
Forming speed: 8-12 m/min
Production process
Uncoiling→Feeding material into machine→Roll forming→Measuring length→
Auto cutting→Products receiving
Components of production line
No. | Name | Unit | Qty |
1 | Decoiler | set | 1 |
2 | Main forming machine | set | 1 |
3 | PLC control system | set | 1 |
4 | Hydraulic pump station | set | 1 |
5 | Post cut | set | 1 |
6 | Electric motor | set | 1 |
7 | Output table | set | 1 |
Detailed introduction of every part for this production line
1.Un-coiler System
Usage: It is used to support the steel coil and uncoil it in a turntable way.
Passive uncoil pulled by roll forming system
Loading capacity | Uncoiling width | Inner diameter |
5T | 1200mm | 450-550mm |
2. Coil feeding part
Usage: Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat,parallel and everything is uniformity.Please refer to the equipment regulation to know the function of locate angle iron.
3. Main Roll Forming System
Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive,chain transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working.
Feature : Ensure stability , precision and lifetime.
4. Cutting device
Advanced hydraulic drive, automatic punching and cutting after forming, no distorting or wasting, high level safety factor. (include cutting tools, hydraulic tank, cutter machine)
| |||||||||||||||||||||||||||||||||||||||||||
5. Counter
One counter gauges length, pulses, and decides length. Omron encoder for length measurement.
6.Products receiving tables
1. It adopts welded steel and supported roller to transmit the products.
2. 3*0.9*0.6m
7. Controlling device
1) Adopted PLC, transducer, touch panel from Delta Taiwan to ensure high speed with
stability, precision and lifetime.
2) Other electric element are Delta
3) Equipped with movable switch, air break, radiator, transformer & electric leakage protector for operation convenience and safety.
| Screen | PLC |
| Text screen displayer | Taida DVP14ES from Taiwan |
8. Hydraulic
(include a set of hydraulic tank , a set of hydraulic oil pump, two hydraulic pipes. And two sets of electromagnetism valves )
Origin | Power |
Advanced hydraulic system from Taiwan | 3kw |
Spare parts ( for free)
1. Easy damaged parts: conk 2 pcs, fuse-link 4 pcs;
2. Rubber mat 1 pcs;
3. Bolt spanner 1 pcs
Remarks
Payment terms | 30% T/T in advance and balance 70% after inspection confirmation before shipment. |
Delivery | within 30 working days after receipt of deposit. |
Packing | Nude packing with 1*40GPcontainer |
Warranty | One year, and we will provide the technical support for the whole life. |
Installation | 1.Training: the buyer should charge of visa, return ticket, food and accommodation overseas and USD50/person/day for salary. 2. Need one technician 3. Training time: one week (contains the time of installation and adjustment) |
Pls send me your drawings profile, then the quotation with all details and our best price will be offered for you at once.
Packing
1. one 40ft container for loading one set machine with manual decoiler;
2. the whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
1. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need
your machines running in order to keep your business running.
2. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour), then we can pick
up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then
we can pick up you.
3. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts repla
ce the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can throug
h negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipme
nt.
4. Can you be responsible for transport?
Yes,please tell me the destination port or address.we have rich experience in transport.
5. How long the machine could be made?
Normally speaking,machine could be made without 30working days. If you need machines in a hurry, we can make it for you about 20days .
Other roll forming machine which you can choose:
1. Trapezoidal tile roll forming machine
2. Corrugated sheet roll forming machine
3. Glazed tile roll forming machine
4. floor decker roll forming machine
Contact Us
- Cangzhou Zhongtuo International Trade Co., Ltd.
- Contact nameRina Xing Chat Now
- Phone0086-317-2191158
- Addressyunhe area taida international building , Cangzhou, Hebei
Product Categories
New Products
-
step tile and trapezoidal profile double layer making machine
-
glazed and trapezoidal double layer tile making machine
-
corrugated and trapezoidal double layer roll forming machine
-
tile making machine south africa
-
tile roll forming machine, trapezoidal sheet metal machine, wall panel roll forming machine
-
color steel galvanized roof wall tile profile making machine
-
high quality roofing machine, trapezoidal shape profile roof tile making roll forming machine
-
refrigerated small trucks/refrigerated van truck aluminum cargo van body forming machine
-
forland refrigerated truck body panels for refrigerated truck body machines
-
T bar truck body panel rolling forming machine
-
Zhongtuo corrugated 1008 and 1000 Trapezoidal Double Layer roll forming machine
-
lorry plate / freight car panel / truck panel roll forming machine
Quality Choice
-
loading lorry panel metal sheet roll forming machine
-
lorry roof panel carriage forming machine roll forming machine
-
Double layer corrugated trapezoidal roof tile wall panel machine glazed tile forming machine floor decking forming machine
-
car panel forming machine car panel making roll forming machine
-
used metal roof panel roll forming machine
-
corrugated sheet metal roof making machine, Double Layer for Corrugated and Trapezoidal Roof Tile Machine
Most Popular
