Semiautomatic powder filler DCS-1B-3
- Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China |
Product Description
Specifications
This machine fits more to the liquid or low-fluidity materials, like milk powder, albumen powder and granular additive etc.Descriptions:
This type can do measuring and filling work. Due to the special design, so it fits more to the liquid or low-fluidity materials, like milk powder, albumen powder, solid drink, white sugar, dextrose, coffee powder, pharmaceuticals, granular additive, dyestuff, and so on.
Features:
l Stainless steel structure; The hopper could be washed easily without tools
l Servo motor drive screw
l PLC, Touch screen & Weighing system control level split hopper
l Weight feedback and proportion track get rid of the shortage of variable packaged weight for various proportion of different material.
l To save all product's parameter formula for later use.Save 10 sets at most.
l Replacing the auger parts,it is suitable for material from super thin powder to granule.
Metering Mode | Auger rotation filling traced by weighing feedback |
Packaging Weight | 10 - 5000g(The screw attachment is to be changed) |
Packaging Accuracy | ≤ 100g, ≤±2%; 100 - 500g, ≤±1%; ≥500g, ≤±0.5% |
Filling Rate | 40 - 120 times/min |
Power Supply | 3P /220-415V 50/60Hz |
Total Power | 1.4KW |
Total Weight | 280kg |
Overall Dimensions | 1140×710×2200mm |
Hopper Volume | 45L(Enlarged size 65L) |
