Powder Filling Machine with weigher
- Shanghai
- Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | Other, Machinery & Hardware | |
| Packaging Type | Cartons | Packaging Material | Metal | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 1.5KW | Place of Origin | Shanghai, China | |
| Brand Name | minhua | Model Number | DHCS series |
Product Description
Specifications
1.Powder Filling Machine with weigher2.Design for bag powder filling
Powder Filling Machine with weigher
This model is designed mainly for the fine powder which easily to spout dust and height-accuracy packing requirement .based on the feedback sign given by below weight sensor ,this machine do measuring ,two-filling ,and up-down work ,etc ,it is specially suitable for filling carbon powder ,dry powder of fire extinguisher ,and other fine powder which needs high packing accuracy ..
Main Features :
Weight sensor is below the tray ,to do fast filling and slow filling based on the pre-set weight , to guarantee the high packing accuracy .
Servo motor does up-down work driving with tray together ,the up-down rate can be set randomly ,no dust spouts out when filling,....
With servo motor and servo driver controlled auger ,perform stably ,and with high accuracy .
PLC control ,touch screen display ,easy to operate .
Made of stainless steel ,combined hopper ,easily to be cleaned ,
With hand wheel-to adjust the height ,easy to fill many kinds of weight .
With fixed screw installation ,the material quality wont be effected .
Process : put bag /can (container ) on the machine container raise fast filling ,container declines --- weight reaches the pre set number ---slow filling ---weight reaches the goal number --- take the container away manually .
Model | DHCS-5B-1 | DHCS-5B-2 |
Packing Weight | 100g-10Kg | 1-50KG |
Packing Accuracy | 100-1000g , ≤ ± 2g ; ≥ 1000g , ≤ ± 0.1 -0.2 % | |
Filling Speed | 5-30 times /min | 5-25 times /min |
Powder supply | 3P AC208-415V 50-60HZ | 3P AC208-415V 50-60HZ |
Total Power | 2.2Kw | 2.7Kw |
Total Weight | 350KGS | 400KGS |
Overall Size | 1000x850x2300mm | 1100x950x2500mm |
Hopper volume | 70L | 100L |
