Semiautomatic filling and packaging machine
- shanghai
- Credit Card PayPal
You May Like
Product Details
| Condition | New | Automatic Grade | Semi-Automatic | |
| Driven Type | Electric | Voltage | 220 | |
| Power | 1.5kw | Place of Origin | Shanghai, China | |
| Brand Name | MINHUA | Model Number | DCS | |
| Dimension(L*W*H) | 1140x970x2030 | Weight | 260 | |
| Certification | ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Semi-automatic Powder filling machine1.High efficiency powder filling machine
2.GMP/CE small powder filling machine..
This type can do measuring and filling work. Due to the special design, so it fits more to the fluidic or low-fluidity materials, like milk powder, gourmet powder ,solid drink, white sugar, dextrose, coffee, fodder , solid medicine, agriculture pesticide, granularity additive, dyestuff, and so on. LCD( in Chinese or English), Servo-motor driving screw. The surface of whole machine is made by stainless steel material except of motor. Knockdown transparent hopper, which could be washed without tooling.
Dexterous and flexible, easy removal. There is no limit of packaged container. It is widely used invariable materials and package-weight specifications.
High speed response(exclusive in china)on-off or servo motor drive screw .High precision, high speed, big torsional moment, long life to use.
LCD or LED ,simply visual supervisory .Stepless adjust the net weight. Change the working parameter at any time, easy to control. Change the working parameter at any time, easy to control.
Save the parameter of each product to later use. 10 sets of magistral fomula save at the most.
Fit for lots of material range from fine-powder to coarse-granule, if change the screw attachment. Dust- collector set on dust material situation to absorb dust spout out
Main Specification | |
Metering Mode | screw rotation filling traced by weighing feedback |
package weight | 10 — 5000g (The screw attachment is to be changed) |
weighing range | package weight ≤ 100g, with an error≤±2% |
| 10 — 500g,with an error≤±1% |
| 500g,with an error≤±0.5% |
packaging rate | 10 — 45bags/min |
power supply | three-phase 380V 50 — 60Hz |
Total power | 1.5KW |
Total Weight | 260Kg |
Overall Dimensions | 1140×970×2030mm |
Hopper Volume | 45L(70 liter for oversized hopper) |
