1.Design the installation drawings according to your site

2.1 year warranty, engineers available to service at any time.

3.Periodical call visit, to make sure there is no problems of the equipment.

4.Design specific maintainence program according to different situation of your plant.

5.For each set of waste plastic pyrolysis oil refining system, one technician will be sent to guide your installation, test the machine and train your workers. Besides, we will provide one month's service for free. After one month, the salary for the technician will be USD65.00/day.

We, Beston

(Henan) machinery Co.Ltd., are one of the professional manufacturers specializing in pyrolysis machine,oil distillation machine and carbon black processing machine. Having been in this field for 15 years, we promise that our convert waste plastic to oil plant adopts highly advanced technonogy and has the features of increasing oil output 5%, saving energy 30%, protecting the environment and ensuring safety 100%.

1. How many tons per day can your systems process?

For our tire pyrolysis machine, we have 3 standard models.

Batch system: Model WJ-6(6T/D); Model WJ-8(10T/D); Continuous system; Model WJ-9(20T/D);

For our continuous waste tire pyrolysis plant is configured with tyre shredder system, auto feeding system, auto carbon&steel discharging system. The plant can be fed material and discharge carbon & steel automatically and sealed, under 350 degree temperature.

*1-. About our 20 tons continuous waste tire pyrolysis plant, it can work continuously with scheduled maintenance(once one or two weeks). So the plant can work 25 days per month.

*2-. The operating details for 20 tons per day: first feeding(5 tons material)→pyrolysis process→second feeding(5 tons material)→pyrolysis process→slag discharging for 2 hours→third feeding(5tons material)→pyrolysis process→the last feeding(5tons material)→slag discharging totally. And for20 tons capacities, about 24 hours will be needed in total.

2. I need to know the Quality of the Fuel Oil and Carbon Black produced. I need chemical test/analysis reports for both.

Enclosed the SGS report of fuel oil and carbon black in the file, pls check.

3. Will it process tires whole or shredded tires only?

Batch system: Model WJ-6(6T/D); Model WJ-8(10T/D); Continuous system; Model WJ-9(20T/D);

For our Manual system, if the diameter of the whole waste tire is under 1.2m, we could process the whole tire directly. While, for our continuous system, beforeprocessing them, we need to using the tire shredder to cut the whole waste tire into piece—30cm-50cm, then using the auto feeding system to send them into the reactor to process.

4. What is the total operational space, including maintenance clearances required per each system?

The smallest occupied area of Model WJ-6(6T/D) or Model WJ-8(10T/D) is 10m*30m*10m(L*W*H), while the smallest occupied area ofModel WJ-9(20T/D) is 10m*40m*10m(L*W*H).

Generally the size of 2000 square meters for the factory is enough. If it is convenient, could you send us the layout of your factory, then based on the layout of your factory, we could design the layour of the whole production line for you.—Comment from our engineer.
