Continuous Tyre Pyrolysis Plant Waste Tire Pyrolysis to Oil Machinewith High Oil Yield

Our pyrolysis machine can convert  waste plastic, tyre and rubber etc into fuel oil in normal pressure. In general, we can get 1 ton fuel oil with 2.5 tons waste tyre or plastic, the fuel oil can be refined throught the oil distillation machine to the deisel, gasoline, and machine oil. Zero emission, high effiency, our pyrolysis plant  not only can resolve the problem of the waste plastic/tyre and pollution, but also can bring substantial benefits for you. We can also supply

        • Used Oil Distillation Plant

        • Carbon Black Processing Plant

Raw Material

End Products and Usage

Technical Parameters

Advantage features

1.The first in the world to have created the new heating structure that combined the advantages of burning the reactor and heating the main reactor by hot air.

2.The technology of avoiding the reactor of being burnt through by reforming the furnace, which will lengthen the life span of the main reactor for 2 to 3 years which saves quite amount of money for customers to maintain and update the continuous and batch used tire pyrolysis equipment, and reduces the rate of depreciation of WJ-6 tire recycling equipment.

3.The technology of improving the oil output by another 5% with the same machine.

Environmental friendly

1.Totally sealed reacting system, and slag discharging system, which prevent odor and ash releasing out.

2.Extra gas purifing system, remove chemical and impurity then recycle it into furnace for heating, clean and energy recycling.

3.6 generation hot some cleaning system, configured with filtering tank, liquid cleaning chamber, liquid sprayers and chimney, make emission meet EU standard. Please refer the scene picture of our Turkey factory:

Energy saving

1.Latest heating system, combined hot smoke heating and fire directly heating. improve heating effeciency for 20% and save energy for 15-20%.

2.New designed reactor case, with particular thermolith and asbestos cover. Increase life time and make reactor get heated uniformly.

3.Specific reactor case cover, keep kcal from transmited to air in workshop.

Operation security measures:

1.Auto alarm system for over temperature and pressure.

2.Auto pressure releasing system to keep emergency situations into safty.

3-Auto operating control panal keep operator from high risk area.

3D Layout

  Reactor

Gas Manifold

Heavy Oil Tank

 Condensers

Oil Storage Tank

Hydroseal

Running plant in Jordan-2012

Running plant in India-2011

1.Design the installation drawings according to your site

2.For each set of waste plastic pyrolysis oil refining system, one technician will be sent to guide your installation, test the machine and train your workers. Besides, we will provide one month's service for free. After one month, the salary for the technician will be USD65.00/day.

3.1 year warranty, engineers available to service at any time.

4.Periodical call visit, to make sure there is no problems of the equipment.

5.Design specific maintainence program according to different situation of your plant.

We, Beston(Henan) machinery Co.Ltd.,

are one of the professional manufacturers specializing in pyrolysis machine,oil distillation machine and carbon black processing machine. Having been in this field for 15 years, we promise that our  products adopts highly advanced

technonogy and has the features of increasing oil output 5%, saving energy 30%, protecting the environment and

ensuring safety 100%.

1. Where have you installed working plants?  What is the feed stock for these plants?

 Place installed working plants: Poland, India, Malaysia, Turkey, nearby our factory , etc.

Feed stock for these plants: waste plastic, rubber, tyre, etc.

2. How soon can a visit be arranged to see a working facility as well as your production factory?

Any time we are waiting for you to see a working facility nearby our factory, sir.

3. When can we arrange a meeting or teleconference to discuss your system in detail?

Ready to arrange a meeting or teleconference to discuss details at any times.

accompany with you to visit the factory. If time rest, we can go to visit the scenic spots together.

4. What is the fuel source for your heating system?  We would prefer natural gas or electric.

Fuel source for heating system: coal, charcoal and wood,natural gas or electric.

The feasibility analysis for electricity heating: The reactor will not be heated uniformly, that will limited the processing time andeffects (oil output rate,quality and reactor life time discount varying degrees), so you are not suggested to use this way to heat

5. Have you worked with engineers in the US regarding air quality and permits?

We have got CE and ISO certificatin. Surely get permits in the US.
