Home > Products > Grinding Machine > 1206T high precision centerless grinder machine for sale
1206T high precision centerless grinder machine for sale
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Type | Other, Centerless Grinding Machine | |
| CNC or Not | Normal | Max. Grinding Diameter | 1~60mm | |
| Max. Grinding Length | 200mm | Place of Origin | Liaoning, China | |
| Brand Name | LFM | Model Number | LFM-1206T centerless grinding machine | |
| Voltage | Customized | Power(W) | 7.5kW | |
| Dimension(L*W*H) | 1800x1400x1450 mm | Weight | 1770kgs | |
| Certification | ISO9001:2008; GB/T19001:2008; | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1206T high precision centerless grinder machine
Specifications | Unit | Parameter |
Standard work rest (dia.) | mm | Φ1 ~ Φ35 |
Special work rest (dia.) | mm | Φ40 ~ Φ60 |
Grinding wheel size | mm | Φ305×150×Φ120 |
Regulating wheel size | mm | Φ205×150×Φ90 |
Grinding wheel speed (speed less) | rpm | 12~1850 |
Regulating wheel speed | rpm | 0~300 |
Grinding wheel motor |
| 7.5HP(5.5kW)AC380V/50Hz |
Regulating wheel motor |
| 2.6HP(2kW)AC380V/50Hz |
Hydraulic pump motor |
| 1HP(0.75kW)AC380V/50Hz |
Coolant pump motor |
| 1/8HP(180W)AC380V/50Hz |
Regulating wheel feed on hand wheel | mm | 3.5 (Rev) 0.05 (Gra) |
Regulating micro feed on hand wheel | mm | 0.1 (Rev) 0.001 (Gra) |
Table feed on hand wheel | mm | 7 (Rev) 0.05 (Gra) |
Table micro feed on hand wheel | mm | 0.2 (Rev) 0.001 (Gra) |
Dressing hand wheel | mm | 1.5 (Rev) 0.01 (Gra) |
Regulating wheel tilt angle |
| +5° ~ -3° |
Regulating wheel swivel angle |
| ±5° |
Machine dimensions (L × W × H) | mm | 1800×1400×1450 |
Package dimension (L × W ×H) | mm | 2000×1700×1800 |
Net weight / Gross weight | kgs | 1770/1920 |
Working accuracy |
|
|
Roundness | mm | ≤0.001 |
Straightness | mm | ≤0.002 |
Roughness |
| ≤0.2Ra |
Size accuracy | mm | ≤0.002 |
No | Item | Note |
1. 1. | Grinding wheel and flange | yes |
| Thru feed standard work rest and blade | yes |
| Hydraulic tank | yes |
| Diamond tool | yes |
| Work piece presser | yes |
| Leveling screw and plate | yes |
| Regulation wheel and flange | yes |
| Infeed standard work rest and blade | yes |
| Work lamp | yes |
| Flange extractor | yes |
| The box and tools | yes |
| Standard electrical equipment | yes |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Delivery Time:
- Normally, 30~60 days, however, different sizes of machines, delivery time will be different, pls consult for exact machine.
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
