M818 manual surface grinding machine

FOB Price

US$ 3,117 - 3,217 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Surface Grinding Machine
CNC or Not	Normal	Max. Grinding Diameter	400mm
Max. Grinding Length	1100mm	Place of Origin	Shanghai, China
Brand Name	LFM	Model Number	M818 manual surface grinding machine
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	1.5kW
Dimension(LWH)	1330x1150x1680mm	Weight	920kgs
Certification	CE; ISO9001:2008; GB/T 19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

M818 manual surface grinding machine

Main Features

Such manual surface grinding machine has following features:

compact construction, excellent capability, and suitable to grinding surface and complex form surface by form dressed whell.

it can be performed without power feeding.

the distance between the grinding wheel and working table has been enlarged;

reliablity, flexibility, high accuracy, high rigidity, small thermo-deformation and low noise;

CE Standard and CE Certificate;

Main Technical Data

Item/ Model	Unit	M818A
Max. width to be ground	mm	220
Max. length to be ground	mm	470
Max. height to be ground	mm	350
Table size	mm	210x450
Permanent magnetic chuck size(optional)	mm	200x400
Max. longitudinal travel	mm	500
Max. cross travel	mm	240
Distance from spindle center to table surface	mm	450
Feed of vertical handwheel(Per rev.)	mm	1
Feed of vertical handwheel(Per div.)	mm	0.005
Grinding wheel size(ODWID)	mm	200x13x31.75
Spindle speed	r/min	3450(60Hz) 2850(50Hz)
Power of spindle head	kW	Standard 1.5(build in spdindle:1.1kW)
Max. load capacity (include permanent magnetic chuck)	kg	128
Machine weight	kg	920
Machine appearance size(L x W x H)	mm	1330x1150x1680
Package dimension(L x W x H)	mm	1153x1413x1950
Package size(dismantle table) (L x W x H)	mm	1400x1120x1980

Real Photos:

Kinds of colors for your choice/can be Customized according to user's demand;
