Catalogue of MDH cnc horizontal machining center for sale

Item

unit

FMH-500 (No.40)

FMH-500 (No. 50)

FMH-630

FMH-800

Travel of X-axis

mm

762

730

1000

1250

Travel of Y-axis

mm

710

710

850

1050

Travel of Z-axis

mm

710

710

850

1000

Table top to spindle center distance

mm

50~760

50~760

50~900

Table top to spindle center distance

mm

150~860

200~910

200~1050

Distance from worktable to ground

mm

1200

1200

1300

Table size

mm

500x500

500x500

630×630

Table indexing

1°× 360°

1°× 360°

1°× 360°

1°× 360°

Max.load capacity of worktable

Kg

500/600

500/600

1200

1500

Spindle speed

rpm

8000

OPT:10000

6000

OPT:8000

6000

Optional: 8000

6000

Optional: 8000

Spindle internal taper

7/24 No.40

7/24 No.50

7/24 No.50

7/24 No.50

Spindle diameter

mm

Φ85

Φ100

Φ100

Φ100

Motor power of spindle

KW

7.5/11

7.5/15

11/18.5

18.5/22

Rapid feed of X/Y/Z

m/min

30

30

24

24

Cutting feed rates

mm/min

1~8000

1~8000

1~8000

1~8000

Tool storage capacity

40 Optional: 60/90/120

40 Optional: 60/90/120

40 Optional: 60/90/120

40 Optional: 60/90

Knife handle form

BT40

BT50

BT50

BT50

Maximum tool weight

kg

8

20

20

20

Maximum tool length

mm

300

400

400

400

Maximum tool diameter

mm

Φ85 (full)

Φ140 (Adjacent empty)

Φ125 (full)

Φ220 (Adjacent empty)

Φ125 (full)

Φ220 (Adjacent empty)

Φ125 (full)

Φ220 (Adjacent empty)

Time of tool change

s

2 (T-T)

8 (T-T)

12 (T-T)

12 (T-T)

Change type

Swing type

Swing type

Swing type

Swing type

Exchange Time of worktable

s

6

6

6

6

Positioning accuracy

mm

X±0.0025

Y/Z±0.0025

X±0.0025

Y/Z±0.0025

X±0.0025

Y/Z±0.0025

X±0.0025

Y/Z±0.0025

Repeat positioning accuracy

mm

X±0.0015

Y/Z±0.0015

X±0.0015

Y/Z±0.0015

X±0.0015

Y/Z±0.0015

X±0.0015

Y/Z±0.0015

Machine covers an area of size

mm

3130x3950

3723x3950

4160x5960

Height of Machine

mm

2970

3170

Machine weight

kg

13500

16000

19000

23000

Power capacity

KVA

40

40

50

50

Air source pressure

bar

6~8

6~8

6~8

6~8
