VDL500/600 smaller hot sale cnc vertical machining center
- 300 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
VDL1000(new designed) linear way cnc vertical machining center for sale
-
VDL1200 Linear Way CNC Vertical Machining Center
-
CE Certified Linear Way and Box Way Vertical Machining Center
-
Catalogue of CNC Vertical Machining Center with Linear Guide Ways
-
CE Certified Linear Way Vertical Machining Center Hot-sale VDL1000
-
CE Vertical Machining Center Hot-sale VDL600
Product Details
| Condition | New | Type | Vertical | |
| Place of Origin | Liaoning, China | Brand Name | DALIAN | |
| Model Number | VDL500 VDL600A vertical machining center | Voltage | Customized | |
| Power(W) | 3.7/7.5kW | Dimension(L*W*H) | 2310x2040x2337mm | |
| Weight | 2000/4800kgs | Certification | ISO9001:2008; GB/T19001:2008; CE | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
VDL500/600 cnc vertical machining center
1. With CE Certificate;
2. National Inspection-free products
3. Highly rigid and stable machine structure;
4. High precision linear on all three-axis;
5. High precision spindle and High spindle speed: 8000~10000rpm;
6. Fast and reliable tool changing mechanism;
7. Cooling system;
8. Multi-functional CNC control system, such as: FANUC, SIEMENS, FAGOR, REXROTH, MITSUBISHI, etc;
Specifications | Unit | VDL500 vmc | VDL600A vmc |
Table(L×W) | mm | 700×320 | 800×420 |
T-slot(Numbers×Width×Distance)(b/t slots) | mm | 3×14×110 | 3×18×125 |
Max. Table load | kg | 150 | 500 |
The distance from spindle center line to column guide way surface | mm | 430 | 511 |
The distance from spindle nose end face to table upper surface | mm | 140~520 | 150~670 |
X/Y/Z travel | mm | 450/350/380 | 600/420/520 |
X/Y/Z guide way type |
| Linear way | Linear way |
X/Y/Z rapid traverse speed | m/min | 30/30/30 | 24/24/20 |
Feed rate | mm/min | 1~10000 | 1~10000 |
X/Y/Z servo motor power | kW | 1.4/1.4/1.6 (1.2/1.2/1.8) ( 2.85/2.85/2.85) | 3/3/3 (1.2/1.2/1.8) (1.8/1.8/2.5) |
X/Y/Z servo motor torque | N.m | 7/7/7 | 11/11/11 |
Positioning accuracy | mm | 0.016 | X/Z:0.020 Y:0.016 |
Repeat positioning accuracy | Nm | 0.006 | X/Z:0.008 Y:0.006 |
Spindle motor power | kW | 3.7/5.5 | 7.5/11 |
Spindle speed range | r/min | 60~10000 | 60~8000 |
Spindle taper |
| #40(7/24) | #40(7/24) |
Tool magazine capacity/Type |
| 12/drum | 16/drum |
Tool adaptor type |
| BT40 | BT40 |
Max. Tool weight | kg | 6 | 7 |
Max. Tool diameter/length | mm | 80/200 drum | 100/280 drum 77/280 swing arm |
Time of tool change(T-T) | sec | 6~8 | 6~8/3.5 |
Air pressure requirement | MPa | 0.6 | 0.6 |
Power requirement | kW | 15 | 25 |
Overall dimension(L×W×H) | mm | 2450×1590×2200 | 2310×2040×2337 |
Net weight | kg | 2000 | 4800 |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
