Product Description
NDW-100/200/500 100N/m Computerized Material Torsion Testing Machine
Phone/whatsapp:+86-15866781190 Skype: hstbetty009
NDW-100/200/500 100N/m Computerized Material Torsion Testing Machine
1. Introduction
This series torsion testing machine is suitable for metal materials, non-metallic materials, composite materials and components of torsion performance test.
Standard :
GB/T 10128-1998 Metal room temperature torsion test method
GB/T 10128-2007 Metal room temperature torsion test method
3. Technical parameter :
|
Model |
NDW-100 |
NDW-200 |
NDW-500 |
NDW-1000 |
NDW-2000 |
NDW-3000 |
NDW-5000 |
|
|
Maximum Torque(N/m) |
100 |
200 |
500 |
1000 |
2000 |
3000 |
5000 |
|
|
Control Method |
Constant torque and constant speed rotation, constant speed twist angle , close loop control mode |
|||||||
|
Machine level |
1 Class |
|||||||
|
Torque Test Range(F·S) |
2%~100%F·S |
|||||||
|
Torque value relative error(%) |
≤±1 |
|||||||
|
Torque display resolution |
1/20000 |
|||||||
|
Torsional Angle Test Range(F·S) |
2%~100% |
|||||||
|
Torsional Angle value relative error (%) |
Better than ±0.5 |
|||||||
|
Torsional Angle display resolution |
1/20000 |
|||||||
|
intersection angle value relative error (%) |
≤±1 |
|||||||
|
intersection angle display resolution(°) |
0.01 |
|||||||
|
Max. torsion Angle |
99999° |
|||||||
|
Torsional angular rate control range (°/min) |
0.05-800 |
|||||||
|
Chuck spacing effectively (mm) |
600 |
|||||||
|
Power Supply |
220V±10%,50Hz |
|||||||
3. Configuration
3.1 Desktop high strength wire torsion host--- 1 Set
3.1.1 High precision arc synchronous gear system --- 1 Set
3.1.2 Efficient cycloidal reducer --- 1 Set
3.1.3 High precision Taiwan ABBA linear bearings --- 1 Sets
3.1.4 Reverse the special auxiliary equipment
3.2 Measurement and Control Systems:
2.1 Photoelectric revolving speed measuring device ---- 1 Set ;
2.2 DC speed governing drive ---- 1 Set ;
2.3 DC variable speed motors---- 1 Set ;
3.2.4 High precision torsion sensor --- 1 Pc
3.2.5 Lenovo Computer --- 1 Set
3.2.6 HPA4 Color Printer --- 1 Set
3.2.7 Measurement and control system --- 1 Set
3.2.8 Windows operate testing machine control software --- 1 set
