Dental Material Testing Machine，Adhesive Bond Tester

**WDW-05E Peel Strength Tester – Specifications (English Version)**

Classic and practical model, widely used and highly praised for its mature technology, low failure rate, and market-proven reliability.

**Standard Functions**

Tension, compression, bending, rebound, peel, indentation hardness, shear, puncture, and other mechanical tests; conforms to GB, DIN, ISO, JIS, ASTM, etc. Automatically calculates max. force, break force, compression force, yield stress, tensile strength, bending strength, modulus, elongation, etc.

1. Max. force: 500 N

2. Load cell capacity: 50 kg (500 N)

3. Accuracy class: 0.5

4. Force range: 1 % – 100 % FS

5. Force resolution: ± 1/500,000 FS (no subdivision, constant)

6. Force control rate: 0.001 % – 10 % FS/s

7. Force-rate accuracy: ± 0.2 % (0.001–1 % FS/s); ± 0.5 % (1–10 % FS/s)

8. Force hold accuracy: ± 0.002 % FS

9. Deformation range: 0.5 % – 100 % FS

10. Constant-force/constant-deformation/constant-position range: 0.2 % – 100 % FS

11. Accuracy of constant modes: ± 1 % (<10 % FS/s set); ± 0.5 % (≥10 % FS/s set)

12. Deformation resolution: ± 1/500,000 FS (no subdivision, constant)

13. Deformation control rate: 0.001 % – 10 % FS/s

14. Deformation-rate accuracy: ± 0.2 % (0.001–1 % FS/s); ± 0.5 % (1–10 % FS/s)

15. Deformation hold accuracy: ± 0.02 % FS

16. Crosshead displacement resolution: 0.01 mm

17. Displacement accuracy: ± 0.2 %

18. Position control rate: 0.01 – 500 mm/min

19. Position-rate accuracy: ± 0.2 %

20. Position hold accuracy: zero error

21. Test space: >900 mm (tension & compression)

22. Control: fully computerised automatic control

23. Safety: over-current, over-voltage, under-current, under-voltage, phase-loss, phase-error, leakage protection; triple travel-limit (program, hardware, software); emergency stop

24. Power supply: 220 V, 50 Hz

25. Power: 1 kW

26. Frame type: single-column, dual-space, compact, elegant, smooth operation

27. Operating environment: ?10 °C – 40 °C, RH 10 % – 95 %

28. Overall dimensions: 520 × 460 × 1650 mm
