Module spare parts 60M100-00

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Table 36: Logic functions Table 37: Configuration and Settings Table 38: Remote communication Delay function: - Adjustable trip delay and drop delay - Two time integration modes - Input invertible 0 to 300 s in steps of 0.01 s Counting function: - Adjustable trip counting threshold and drop delay - Input invertible 1 to 100 in steps of 1 AND function - Maximum of four inputs - All inputs invertible - Trip with additional delay or counting function OR-function - Maximum of four inputs - All inputs invertible - Trip with additional delay or counting function FLIP-FLOP function - Two set- and two reset inputs - All inputs invertible - Trip with additional delay or counting function Locally via the comm. port on the front-plate using an IBM AT or compatible PC User interface program CAP2/316 in English, German or French on a CD RS232C interface Data transfer rate Protocol Electrical/optical converter (optional) 9600 Bit/s SPA or IEC 60870-5-103 216BM61b PC-Card interface Number 2 plug-in sockets for type 3 cards (for 2 processing units 216VC62a) PC-Cards (optional) interbay bus protocol process bus protocol (interbay and process bus can be used concurrently) LON bus Data transfer rate IEC 61375 bus Data transfer rate LON or MVB (part of IEC 61375) MVB (part of IEC 61375) PC-Card with fibreoptic port, ST connectors 1.25 MBit/s PC-Card with redundant fibreoptic port, ST connectors 1.5 MBit/s Event memory Capacity Time marker resolution 256 events 1 ms Time deviation without remote synchronization <10 s per day Engineering interface integrated software interface for signal engineering with SigTOOL Numerical Generator Protection REG216 / REG216 Classic 1MRB520004-Ben Page 26 Technical data (cont′d) ABB Switzerland Ltd Power Technology Systems Table 39: Contact data Table 40: Auxiliary supply Tripping: Max. operating voltage 250 VAC or VDC Make and carry for 0.5 s 30 AAC or A DC Continuous current 10 A AC or A DC Making power 2500 VA Rupture current with two contacts in series and L/R = 40 ms at U ≤50 VDC at U ≤120 VDC at U ≤250 VDC 5 A 1 A 0,3 A Signalling stand by No. of contacts (216GA61) No. of contacts (216GD61a) 2 break contacts per signalling channel 1 make contact per signalling channel 4 signalling channels with 1 break contact Max. operating voltage 250 VAC or VDC Make and carry for 0.5 s 10 AAC or ADC Continuous current 5 AAC or ADC Making power 1250 VAAC 60 WDC Max. installed rating per cubicle 400 W Supply interruption bridging time at min input voltage and full load at rated input voltage and 70% load >10 ms >50 ms Table 41: General data Temperature range operation storage -10° C to +55°
