Module spare parts 7DO135.70

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Parameters Range of values Default Parameter reassignment in RUN Scope with configuration software, e.g. STEP 7 (TIA Portal) GSD file PROFINET IO GSD file PROFIBUS DP 1 Reaction to CPU STOP ? Turn off ? Keep last value ? Output substitute value 1 Turn off Yes Channel Module Potential group ? Use potential group of the left module (module plugged into a dark-colored BaseUnit) ? Enable new potential group (module plugged into lightcolored BaseUnit) Use potential group of the left module No Module Module 1 Due to the limited number of parameters of a maximum of 244 bytes per ET 200SP station with a PROFIBUS GSD configuration, the parameter assignment options are restricted. The parameter length of the I/O module is 6 bytes with PROFIBUS GSD configuration. If necessary, you can set this parameter by using the data record 128, see the appendix "Parameter data record". Note ? If both parameters "Diagnostics: short-circuit to L+" and "Diagnostics: wire break" are enabled and one of these diagnostic events occurs, the affected channel is switched off. This prevents undefined load switching and the corresponding diagnostic alarm is triggered. ? If both parameters "Diagnostics: short-circuit to L+" and "Diagnostics: wire break" are enabled and one of these diagnostic events occurs, the affected channel is switched off. This prevents undefined load switching and the corresponding diagnostic alarm is triggered. ? If the parameter "Diagnostics: short-circuit to L+" is enabled and "Diagnostics: wire break" is disabled, the signal status is retained at the affected channel when "Diagnostics: shortcircuit to L+" occurs. A diagnostic alarm is triggered only for 0 signal. Parameters/address space 4.2 Declaration of parameters Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) 16 Manual, 02/2019, A5E03574420-AF 4.2 Declaration of parameters Diagnostics: No supply voltage L+ Enabling of the diagnostics for no or insufficient supply voltage L+. Diagnostics: Short-circuit to ground Enabling of the diagnostics if a short-circuit of the actuator supply to ground occurs. Diagnostics: Short-circuit to L+ Enabling of the diagnostics if a short-circuit of the actuator supply to L+ occurs. Diagnostics: Wire break Enabling of the diagnostics if the line to the actuator is broken. Channel activated Determines whether a channel is activated or deactivated
