Module spare parts 83SR06B-E GJR2395400R1210

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

NovaTech 8000 Series I/O uses the Ethernet Bus Interface Module (EBIM) to provide a high speed Ethernet data connection to the D/3?. The EBIMs communicate using a propri-etary protocol over Ethernet at speeds of 10/100MB to the D/3? PCMs. NovaTech 8000 Series I/O Support 8000 Series I/O offers a variety of I/O boards and signal conditioning termination panels suitable for virtually every standard process sensor and actuator. Details on signal conditioning termination panels, as well as their associated I/O function boards, can be obtained in individual specification sheets. The standard D/3? configuration supports such I/O signals as: ? Analog Inputs: 4-20 mA, 10-50 mA, 0-10V (programmable ranges of 0-50mV, 0-100mV, 0-1V and 0-10V), 100 ohm platinum RTDs, thermocouples ? Analog Outputs: 4-20 mA, 10-50 mA, 0-10V ? Digital and Pulse Inputs: ? Contact Closures +5, +12, +24 and +10 to +32 VDC ? Contact Closures 95 to 130 VAC ? Pulse Train Inputs up to 100 KHz @ +5, +12, +24 VDC ? Pulse Train Inputs up to 50 Hz @ +10 to +32 VDC and 95 to 130 VAC ? Digital and Pulse Outputs: ? DC Output +5, +12, +24, and +5 to +60 VDC ? AC Output 12 to 140 VAC ? Pulse Output 2 msec. to 3.3 sec. @ +5, +12, +24, and +5 to +60 VDC ? Pulse Output 10 msec. to 11 min. @ +5, +12, +24, and +5 to +60 VDC ? Pulse Output 2 msec. to 3.3 sec. @ 12 to 140 VAC ? Pulse Output 10 msec. to 11 min. @ 12 to 140 VAC 8000 Series I/O ? Product Catalog 8000 Series I/O Copyright ? 2007 NovaTech, LLC. All rights reserved. All trademarks are properties of their respective owners. NovaTech is a registered trademark of NovaTech, LLC. The information in this literature is subject to change without notice and is not to be construed as a warranty. DS_8KIO_0607 Contact: ? NovaTech Process Solutions, LLC 11500 Cronridge Dr., Suite 110 Owings Mills, MD 21117 T: 410.753.8300 Toll Free: 800.253.3842 . 8 single-ended 4-20 mA input channels . Non-incendive field circuits . HART pass-through . HART variable and status reporting . 2- or 4-wire transmitters . open and short circuit detection . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...............................................8, single-ended Nominal signal range (span) ..........................................4 to 20 mA Full signal range.................................................................1 to 23 mA Line fault detection Short circuit current .....................................................> 23.5 mA Open circuit current ......................................................<0.5 mA Output voltage (@ 20mA).............................................13.5 V (min.) Output current ..............................................................32 mA (max.) Accuracy (over temp range) ...................................± 0.1% of span Resolution ..................................................................................16 bits Repeatability ................................................................0.05% of span Isolation (any channel to Railbus) .................................................100 V ac (between channels)................................................................none NT-8101-HI-TX Image Description 8 Channel Analog Input 4–20 mA with HART? Configurable Parameters Input filter time constant .................................user defined value Input dead zone .................................................user defined value Drive on failsafe............................. disabled /upscale /downscale Channel status.......................................................... active /inactive HART variable and status reporting ................... enable /disable Response Time Signal change to availability on Railbus 4–20 mA mode .........................................................27 ms (max.) HART mode......................................................0.75 s per channel Safety FM non-incendive field wiring parameters (each channel) Voc = 28.7 V; Isc = 33 mA; Ca = 0.17 μF; La = 11.0 mH Power Supplies Railbus (12V) current .....................100 mA (typ.), 150 mA (max.) Bussed Field Power 2-wire Tx...................................300 mA (max.) (@ 24 V dc ±10%) 4-wire Tx.........................................60 mA (max.) Mechanical Module Key Code .............................................................................A1 Module width ............................................................................42 mm Weight............................................................................................200 g Field Terminals (2-WIRE TX) Field Wiring Recommended Field Terminal Compatible Field Terminal General Purpose NT-8602-FT-ST Standard NT-8604-FT-FU Fused Class 1, Div 2 or Zone 2 hazardous area NT-8601-FT-NI Non-incendive NT-8603-FT-FU Non-incendive Field Terminals (4-WIRE TX) Field Wiring Recommended Field Terminal Compatible Field Terminal General Purpose NT-8615-FT-4W - Class 1, Div 2 or Zone 2 hazardous area NT-8
