Module spare parts 8115-DO-DC

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Output current ? for signal "1" rated value 0.5 A ? for signal "0" residual current, max. 0.1 mA Output delay with resistive load ? "0" to "1", typ. 50 μs ? "1" to "0", typ. 100 μs Parallel switching of two outputs ? for uprating No ? for redundant control of a load Yes Switching frequency ? with resistive load, max. 100 Hz ? with inductive load, max. 2 Hz ? on lamp load, max. 10 Hz Total current of the outputs ? Current per channel, max. 0.5 A ? Current per module, max. 8 A Total current of the outputs (per module) horizontal installation – up to 30 °C, max. 8 A – up to 40 °C, max. 8 A – up to 50 °C, max. 6 A – up to 60 °C, max. 4 A vertical installation – up to 30 °C, max. 8 A – up to 40 °C, max. 6 A – up to 50 °C, max. 4 A Cable length ? shielded, max. 1 000 m ? unshielded, max. 600 m Isochronous mode Isochronous operation (application synchronized up to terminal) No Interrupts/diagnostics/status information Diagnostics function Yes Substitute values connectable Yes Alarms ? Diagnostic alarm Yes Technical specifications 6.1 Technical specifications Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) 26 Manual, 02/2019, A5E03574420-AF Article number 6ES7132-6BH01-0BA0 Diagnostic messages ? Monitoring the supply voltage Yes ? Wire-break Yes; Module-wise ? Short-circuit to M Yes; Module-wise ? Short-circuit to L+ Yes; Module-wise ? Group error Yes Diagnostics indication LED ? Monitoring of the supply voltage (PWRLED) Yes; green PWR LED ? Channel status display Yes; Green LED ? for channel diagnostics No ? for module diagnostics Yes; green/red DIAG LED Potential separation Potential separation channels ? between the channels No ? between the channels and backplane bus Yes Isolation Isolation tested with 707 V DC (type test) Standards, approvals, certificates Suitable for safety functions No Suitable for safety-related tripping of standard modules Yes; From FS01 Highest safety class achievable in safety mode ? Performance level according to ISO 13849- 1 PL d ? SIL acc. to IEC 61508 SIL 2 Ambient conditions Ambient temperature during operation ? horizontal installation, min. -30 °C ? horizontal installation, max. 60 °C ? vertical installation, min. -30 °C ? vertical installation, max. 50 °C Altitude during operation relating to sea level ? Installation altitude above sea level, max. 2 000 m; On request: Installation altitudes greater than 2 000 m Dimensions Width 15 mm Height 73 mm Depth 58 mm Weights Weight, approx. 30 g Technical specifications 6.1 Technical specifications Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) Manual, 02/2019, A5E03574420-AF 27 Safety-related shutdown Note The digital output module DQ 16x24VDC/0.5A ST supports safety-related shutdown in connection with a fail-safe power module F-PM-E 24VDC/8A PPM ST: ? SIL according to IEC 61508: 2 ? Highest attainable safety class in safety mode, performance level according to EN ISO 13849-1: d Residual current for signal state "0" Note Residual current for signal state "0" Due to the Diagnostics: Wire break function, there is a low level of residual current in the "0" signal state at the output, which may cause the display diodes to flicker. This residual current does not depend on the setting for the Diagnostics: Wire break parameter. Technical specifications 6.1 Technical specifications Digital output module DQ 16x24VDC/0.5A ST (6ES7132-6BH01-0BA0) 28 Manual, 02/2019, A5E03574420-AF Derating trend The following figure show the load current derating with horizontal and vertical mounting positions. Figure 6-1 Load current for mounting position Dimension drawing See manual ET 200SP BaseUnits
