Module spare parts 5X00062G01 5X00063G01

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Table 18: Rotor overload (49 R) Features: Same as stator overload function, but three-phase measurement Settings: Same as for stator overload function Table 19: Inverse time negative phase sequence current (46) Features: ? Protection against unbalanced load ? Inverse time delay ? Three-phase measurement Fig. 6 Inverse time negative phase sequence current protection function characteristics Settings: Base current (IB) 0.5 to 2.5 IN in steps of 0.01 IN Time multiplier k1 5 to 60 s in steps of 0.1 s Factor k2 (pick-up) 0.02 to 0.20 in steps of 0.01 tmin 1 to 120 s in steps of 0.1 s tmax 500 to 2000 s in steps of 1 s treset 5 to 2000 s in steps of 1 s Accuracy of NPS current (I2) measurement +2% (at fN) with measuring transformers Starting time ≤80 ms Table 20: Overtemperature (49) Features: ? Thermal replica for system of first order or general thermal system response ? Single- or three-phase current measurement ? Highest phase value for three-phase measurement Settings: Base current IB 0.5 to 2.5 IN in steps of 0.01 IN Warning stage 50 to 200% ?N in steps of 1% ?N Tripping stage 50 to 200% ?N in steps of 1% ?N Thermal time constant 0.0 to 500 min in steps of 0.1 min Accuracy of current measurement ±2% (at fN) with measuring transformers Accuracy of the thermal image ±5% Numerical Generator Protection REG216 / REG216 Classic 1MRB520004-Ben Page 17 ABB Switzerland Ltd Power Technology Systems Table 21: Frequency (81) Features: ? Maximum or minimum function (over-, underfrequency) ? Minimum voltage blocking Settings: Frequency 40 to 65 Hz in steps of 0.01 Hz Delay 0.1 to 60 s in steps of 0.01 s Minimum voltage 0.2 to 0.8 UN in steps of 0.1 UN Accuracy of pick-up value ±30 mHz (at UN and fN) Reset ratio <106% Starting time <135 ms Table 22: Rate-of-change of frequency df/dt (81) Features: ? Combined pick-up with frequency criterion possible ? Blocking by undervoltage Settings: df/dt -10 to +10 Hz/s in steps of 0.1 Hz/s Frequency 40 to 55 Hz in steps of 0.01 Hz at fN = 50 Hz 50 to 65 Hz in steps of 0.01 Hz at fN = 60 Hz Delay 0.1 to 60 s in steps of 0.01 s Minimum voltage 0.2 to 0.8 UN in steps of 0.1 UN Accuracy of df/dt (at 0.9 to 1.05 fN) ±0.1 Hz/s Accuracy of frequency (at 0.9 to 1.05 fN) ±30 mHz Reset ratio df/dt 95% for max. function 105% for min. function Table 23: Overexcitation (24) Features: ? U/f measurement ? Minimum voltage blocking Settings: Pick-up value 0.2 to 2 UN/fN in steps of 0.01 UN/fN Delay 0.1 to 60 s in steps of 0.01 s Frequency range 0.5 to 1.2 fN Accuracy (at fN) ±3% or ±0.01 UN/fN Reset ratio >97% (max.), <103% (min.) Starting time ≤120 msr Starting time ≤80 ms
