HG-IG 10L High Quality Acetylene Gas Cylinder Price
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
First Hand Low Pressure Acetylene Cylinder/ Acetylene Gas Cylinder
-
2L/5L/10L Low Pressure Little Capacity of Acetylene Gas Cylinder /acetylene Bottle
-
HG-IG 40L Acetylene Cylinder
-
Low Price High Quality Oxygen Acetylene Gas Cylinder
-
HG-IG Acetylene Gas Cylinder Factory Price High Pressure 2L-60L C2H2
-
HG-IG ISO3807/GB11638 ACETYLENE GAS CYLINDER C2H2
Product Description
Product Show
C2H2 Cylinders
HG-IG acetylene cylinders are made by high quality seamless steel pipe, with consistent height, smoothly painting and excellent properties, widely used for industrial field, such as steel cutting, welding, and chemical field as well.
Different countries have diferent standards on acetylene cylinders, including its color, valve, working pressure etc. Customized service is available.
Specifications
Cylinder Model | O.D (mm) | Water Capacity(L) | Height(mm) | Net Weight(kg) | Design Thickness (mm) | Material(Steel) | Max fill Acetone Weight(kg) | Max fill Acetylene Weight(kg) |
HG-AC-60 | φ310 | 60.0 | 1100 | 60.0 | Min 5.0 | HP295 | 20.5 | 10.2 |
HG-AC-40 | φ258 | 40.0 | 1045 | 37.0 | Min 3.3 | HP295 | 13.6 | 6.8 |
HG-AC-30 | φ243 | 30.0 | 790 | 27.0 | Min 3.3 | HP295 | 8.5 | 4.2 |
HG-AC-10 | φ159 | 10.0 | 780 | 13.5 | Min 3.6 | 37Mn | 3.3 | 1.7 |
HG-AC-8 | φ159 | 8.0 | 670 | 12.0 | Min 3.6 | 37Mn | 2.7 | 1.4 |
HG-AC-2 | φ108 | 2.0 | 445 | 4.0 | Min 3.2 | 37Mn | 0.6 | 0.3 |
Acetylene Cylinder Producing Flow Chart
Related Products
Outsider Diameter(mm) 232
Water Capacity(L) 50.0
Height(mm) 1461
Neight Weight(kg) 59.50
Design Thickness(mm) Min 5.2/5.8
Material 34CrMo4
Work Pressure 200Bar
Working Pressure(Bar) 150/250
Testing Pressure(Bar) 250/350
Material 37Mn/34CrMo4
Standard GB5099/ ISO9809/ DOT-3AL
FAQ
Q1: Are you a manufacturer or a trading company?
A1: We are a professional manufacturer engaging in the field of gas system, and have got the permit of export for years as well.
Q2: Can I print our own logo on package?
A2: Sure! Customized package and OEM printing are available.
Q3: What's the payment terms?
A3: Usually 30% T/T advance, balance before delivery.
Q4: What's your delivery time?
A4: Usually 15-20 days, depending on the quantity you ordered.
Q5: Which package of the cylinder?
A5: Bulk in one container; Hard carton; Wooden or Steel Pallet, depending on the goods and quantity, negotiable.
Q6: Can you supply gas filled cylinders?
A6: Of course we can. We have been exporting different gas filled cylinders since year 2009. We have mature channels.
Q2: Can I print our own logo on package?
A2: Sure! Customized package and OEM printing are available.
Q3: What's the payment terms?
A3: Usually 30% T/T advance, balance before delivery.
Q4: What's your delivery time?
A4: Usually 15-20 days, depending on the quantity you ordered.
Q5: Which package of the cylinder?
A5: Bulk in one container; Hard carton; Wooden or Steel Pallet, depending on the goods and quantity, negotiable.
Q6: Can you supply gas filled cylinders?
A6: Of course we can. We have been exporting different gas filled cylinders since year 2009. We have mature channels.
