Product Description
Product Description
305805 C-2Z Cam Follower Bearing 305805C-2Z Cam Roller Bearing 25*62*20.6mm
The double-row angular contact ball bearing Features
* angular ball bearing with two rows of balls
* suitable for high radial loads and axial loads in both directions
* suitable for high running accuracy, quiet running and high speeds
* cage material: plastic; the low weight and the elasticity of the plastic have a positive effect on the sliding and emergency
running properties as well as the shock resistance; suitable for quiet running
* seal: open (without seal); for higher speeds than with sealed ball bearings and easy relubrication
* good fixed bearing property, but can also be used as a floating bearing, each in both directions
* manufacturers of bearings, such as , KOYO, NSK, , SNR, etc. assign different suffixes for their characteristics, for
better orientation take note of the comparison table of bearings
* suitable for high radial loads and axial loads in both directions
* suitable for high running accuracy, quiet running and high speeds
* cage material: plastic; the low weight and the elasticity of the plastic have a positive effect on the sliding and emergency
running properties as well as the shock resistance; suitable for quiet running
* seal: open (without seal); for higher speeds than with sealed ball bearings and easy relubrication
* good fixed bearing property, but can also be used as a floating bearing, each in both directions
* manufacturers of bearings, such as , KOYO, NSK, , SNR, etc. assign different suffixes for their characteristics, for
better orientation take note of the comparison table of bearings
Double row design for higher load capacity. The double-row angular contact ball bearing 5210-TN is ideal for high combined loads
from the radial and axial directions. Main dimensions according to DIN 628-3.
from the radial and axial directions. Main dimensions according to DIN 628-3.
Common Applications:
* Machine tools* Gearboxes* Pumps* Printing machinery* Motors* CNC machinery
* Machine tools* Gearboxes* Pumps* Printing machinery* Motors* CNC machinery

Type | Cam Follower Bearing 305805C-2Z Cam Roller Bearing |
nside Diameter (mm): | 30 |
Outside Diameter (mm): | 62 |
Width (mm): | 20.6 |
Rows Of Balls: | double row |
Seal: | open |
Ring Material: | Chrome Steel |
Rolling Element Material: | Chrome Steel |
Cage Material: | Plastic |
Magnetic: | yes |
Product weight: | 0,23Kg |
Cam Follower Bearing 305805C-2Z Cam Roller Bearing 25*62*20.6mm




Related Products
New Model | Old Model | ID(mm) | OD(mm) | Width(mm) | Weight(KG) |
5200 | 3200 | 10 | 30 | 14.3 | 0.049 |
5201 | 3201 | 12 | 32 | 15.9 | 0.057 |
5202 | 3202 | 15 | 35 | 15.9 | 0.064 |
5203 | 3203 | 17 | 40 | 17.5 | 0.096 |
5204 | 3204 | 20 | 47 | 20.6 | 0.153 |
5205 | 3205 | 25 | 52 | 20.6 | 0.175 |
5206 | 3206 | 30 | 60 | 23.8 | 0.286 |
5207 | 3207 | 35 | 72 | 27 | 0.436 |
5208 | 3208 | 40 | 80 | 30.2 | 0.59 |
5209 | 3209 | 45 | 85 | 30.2 | 0.64 |
5210 | 3210 | 50 | 90 | 30.2 | 0.689 |
5211 | 3211 | 55 | 100 | 33.3 | 0.986 |
5212 | 3212 | 60 | 110 | 38.1 | 1.27 |
5213 | 3213 | 65 | 120 | 39.7 | 1.57 |
5214 | 3214 | 70 | 125 | 41.3 | 1.8 |
5215 | 3215 | 75 | 130 | 44.4 | 1.9 |
5216 | 3216 | 80 | 140 | 49.2 | 2.39 |
5217 | 3217 | 85 | 150 | 44.4 | 3.06 |
5218 | 3218 | 90 | 160 | 52.4 | 3.73 |
5219 | 3219 | 95 | 170 | 55.6 | 5.1 |
5220 | 3220 | 100 | 180 | 60.3 | 6.14 |
5221 | 3221 | 105 | 190 | 65.1 | 7.4 |
5222 | 3222 | 110 | 200 | 69.8 | 9.2 |
