Original NSK 50TAC100B Ball Screw Support Bearing 50TAC100BSUC10PN7B
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
7320BDB Angular Contact Ball Bearing F A G 7320BM 7320BMP 100*-215*94
-
H7002 Universal Combination Ceramic Balls p4 Grade Angular Contact Ball Bearing H7002C-2RS 7002 Bearing 15*32*9mm
-
HC 708C 2RS DTP4 Super-precision 8*22*7mm Angular Contact Ball Bearing Hc708e2rsdtp4s 708
-
H708C Angular Contact Ball Bearing HC708.C.T.P4S HC708-E-2RSD-T-P4S
-
25x52x18mm Original Koyo Bearing 70081C3 Cylindrical Roller Bearing 70081
-
95x120x17 mm NSK 95dsf01 Auto Wheel Bearing 95dsf01 95DSF01A1C 90363-95003 Ball Bearing in Stock
Product Description
Product Description
original NSK Angular Contact Ball Bearings 50TAC100B ball screw support bearing 50TAC100BSUC10PN7B
Angular Contact Thrust Ball Bearings for Ball Screw Support
High precision angular contact thrust ball bearings to support precision ball screws, have better performance than earlier
combinations of angular contact ball bearings or combinations using thrust bearings. They are especially suitable for high precision machine-tool feeding mechanisms and similar applications.
TAC B Series (Machine Tool Applications)
TAC02 and 03 Series (Electric Injection Molding Machines)
TAC B and TAC02, 03 Differences

Bearing Model | 50TAC100BSUC10PN7B |
Application | Machine Tool |
Type | 60° Ball Screw Support Ball Bearing |
Structure | Angular Contact Thrust Ball Bearing |
(dxDxB) | 50x100x20 mm |
Weight | 0.84 KG |
Lead Time | Within 3 Days |
Contact | sara (Ms) |
stock | have stock |
WhatsApp / Webchat | +86 18710180456 |
Email | sales1@landlionbearing.com |
Detailed Images
TAC BALL SCREW BEARING
original NSK Angular Contact Ball Bearings 50TAC100B ball screw support bearing 50TAC100BSUC10PN7B










Angular Contact Thrust Ball Bearings for Supporting Screw | ||||||
Model No. | d(mm) | D(mm) | B(mm) | |||
30TAC62BDDG | 30 | 62 | 12 | |||
35TAC72BDDG | 35 | 72 | 15 | |||
40TAC72BDDG | 40 | 72 | 15 | |||
40TAC90BDDG | 40 | 90 | 20 | |||
45TAC100BDDG | 45 | 100 | 20 | |||
15TAC02AT85 | 15 | 35 | 11 | |||
25TAC02AT85 | 25 | 32 | 15 | |||
TAC35-2T85 | 35 | 90 | 23 | |||
40TAC03AT85 | 40 | 90 | 23 | |||
45TAC03AT85 | 45 | 100 | 25 | |||
TAC45-2T85 | 45 | 110 | 27 | |||
50TAC03AT85 | 50 | 110 | 27 | |||
55TAC03AT85 | 55 | 120 | 29 | |||
60TAC03AT85 | 60 | 130 | 31 | |||
80TAC03AM | 80 | 170 | 39 | |||
100TAC03CMC | 100 | 215 | 47 | |||
120TAC03CMC | 120 | 260 | 55 | |||
760202TN1 | 15 | 35 | 11 | |||
760203TN1 | 17 | 40 | 12 | |||
760204TN1 | 20 | 47 | 14 | |||
760205TN1 | 25 | 52 | 15 | |||
760206TN1 | 30 | 62 | 16 | |||
760207TN1 | 35 | 72 | 17 | |||
760208TN1 | 40 | 80 | 18 | |||
760209TN1 | 45 | 85 | 19 | |||
760210TN1 | 50 | 90 | 20 | |||
760211TN1 | 55 | 100 | 21 | |||
760212TN1 | 60 | 110 | 22 | |||
760213TN1 | 65 | 120 | 23 | |||
760214TN1 | 70 | 125 | 24 | |||
760215TN1 | 75 | 130 | 25 | |||
760216TN1 | 80 | 140 | 26 | |||
760217TN1 | 85 | 150 | 28 | |||
760218TN1 | 90 | 160 | 30 | |||
760219TN1 | 95 | 170 | 32 | |||
Certifications

Main Products

Product packaging
Packing :
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment

Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application

Factory


Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
