8*19*6mm High Speed Bearing 719/8 CE/P4AH Angular Contact Ball Bearing 719/8C P4
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
8*22*7mm High Speed 708 Ceramic Angular Contact Ball Bearing 708c
-
Japan NSK Precision Machine Tool Bearings 7010A5TYNSULP4 7010CTYNSULP4 7010
-
Original NTN Screw Support Bearing BST25X62 BST25X62-1BP4 Angular Contact Bearing
-
BSB60120 Ball Screw Support Ball Bearing BSB50100-2Z-SU Angular Contact Ball Bearing BSB60120-2Z-SU
-
BSB1747-2Z-SU Ball Screw Support Ball Bearing BSB55120-2Z-SU Angular Contact Ball Bearing BSB60120-2Z-SU
-
7210 CTRSULP3 NSK Precision Angular Contact Ball Bearing 7214 CTRSULP3
Product Description
Product Description
High Speed NACHI Ball Bearing 719/8 CE/P4AH 719/8C P4 Angular Contact Ball Bearing 8*19*6mm
Structure-Ceramic Ball/Angular Contact ball
Model number- 719/8C P4
Size :Inner ring(mm)-8 Outer ring(mm)-19Width(mm)-6 Weight(Kg)-0.025
Materials-Chrome steel/GCR15
Precision grade-P4/P2
speed:rpm60000-100000rpm
Lubrication type-Grease lubrication
Contact Angle-C=15°;AC=25°
Material(Ball)-SN24:Ceramic ball(Si3N4)
Number of Row-Single rows
Material(Cage)-TN /PN
Combination-
SU:Universal combination (single row)
DU:Universal combination (double rows)
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
DB: Back-to-back combination
DF: Face-to-face combination
DT: Parallel combination
DBD.DFD.DTD: Three rows
DBB.DFF.DBT.DFT.DTT: Four rows
Categories:Angular Contact Ball Bearings Ceramic Ball Bearings
Related Search:708AC / CHQ1P4,708C Ceramic Ball Bearings,708C Spindle bearing,708C High Speed Bearing
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
Product Features
Angular Contact Ball bearing with Ceramic balls (Si3N4), used in high precision Spindle and Motors
Series Introduction
High Speed Ceramic Ball Type:ISO 10 Series - highest load, second lowest speed
bearings-70 Series Angular Contact Bearings Series
Model No.
7000HQ1,7001HQ1,7002HQ1,7003HQ1,7004HQ1,7005HQ1,7006HQ1,7007HQ1,7008HQ1,7009HQ1,
7010HQ1,7011HQ1,7012HQ1,7013HQ1,7014HQ1,7015HQ1,7016HQ1,7017HQ1,7018HQ1
Applications High Speed Ceramic Ball Angular contact bearing applications :
electric motors,Spindle,automotive applications, home appliances, industrialequipment
name | High Speed NACHI Ball Bearing 719/8 CE/P4AH 719/8C P4 |
ball material | Si3N4 or chrome steel |
ID | 8 mm |
OD | 19 mm |
B | 6 mm |
Product weight | 0.011kg |
Cage Material: | TN |
material | chrome steel |
Tel | +86-18710180456 |
Related Products
bearing | d | D | B | c | Da | da | contact angle | weight KG |
B7000-C-2RSD-T-P4S-UL | 10 | 26 | 8 | 6.4 | 22 | 14 | 15° | 0.02 |
B7001-C-2RSD-T-P4S-UL | 12 | 28 | 8 | 6.7 | 24.5 | 16.5 | 15° | 0.02 |
B7002-C-2RSD-T-P4S-UL | 15 | 32 | 9 | 7.6 | 28 | 19 | 15° | 0.03 |
B7003-C-2RSD-T-P4S-UL | 17 | 35 | 10 | 8.5 | 32 | 21 | 15° | 0.04 |
B7004-C-2RSD-T-P4S-UL | 20 | 42 | 12 | 10.2 | 37 | 25 | 15° | 0.07 |
B7005-C-2RSD-T-P4S-UL | 25 | 47 | 12 | 10.8 | 42 | 30 | 15° | 0.08 |
B7006-C-2RSD-T-P4S-UL | 30 | 55 | 13 | 12.3 | 49 | 36 | 15° | 0.11 |
B7007-C-2RSD-T-P4S-UL | 35 | 62 | 14 | 13.5 | 56 | 41 | 15° | 0.15 |
B7008-C-2RSD-T-P4S-UL | 40 | 68 | 15 | 14.7 | 62 | 46 | 15° | 0.19 |
B7009-C-2RSD-T-P4S-UL | 45 | 75 | 16 | 16 | 69 | 51 | 15° | 0.24 |
B7010-C-2RSD-T-P4S-UL | 50 | 80 | 16 | 16.7 | 74 | 56 | 15° | 0.25 |
B7011-C-2RSD-T-P4S-UL | 55 | 90 | 18 | 18.7 | 83 | 62 | 15° | 0.38 |
B7012-C-2RSD-T-P4S-UL | 60 | 95 | 18 | 19.4 | 88 | 67 | 15° | 0.4 |
Product packaging
Packing ：
1. Industrial packing
2. Single box +carton +pallets /case
3. According to customers demand
Delivery time :
1. Generally after payment: within 3 days .
2. If need produce , about 30 days
Payment
A less USD1000 , 100% T/T in advance .
1. More USD1000 , 30% T/T in advance , 70%T/T before shipment
Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...
Application
Factory
Company introduction
LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and trader .
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
