Sand and Gravel Making Machine
US$ 5000 - 8000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T L/C PayPal Other
- 30 days
You May Like
Product Details
| Brand Name | Shisheng Machinery | Place of Origin | China | |
| Model Number | PCL-600 | Certification | ISO, CE | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 years | |
| Weight | 5.6t | Dimension(L*W*H) | 2800*1500*2030mm | |
| Production Capacity | 12-30t/h | Condition | New | |
| Voltage | 380V 50HZ or Customized | Power(W) | 2*30kw |
Product Description
Sand and Gravel Making Machine
High Efficiency Sand and Gravel Making Machine Features:
The structure is simple, and the operating cost is low.
High efficiency, and low consumption.
It can be fine crush, crude grind material and it is easy to maintain.
It is slightly influenced by the humidity of material, and the max. humidity is 8%.
It is more suitable for crushing mid-hardness materials and high-hardness materials.
Its product is cubic, and the density of pilling up is high and the iron pollution is low.
The working noise is less than 75 decibels and dust pollution is light.
Sand and Gravel Making Machine Technical Parameter:
| Model | Impeller Speed(r/min) | Max.Feed Size(mm) | Capacity(t/h) | Power(kw) | Weight(t) | Overall Dimension(mm) |
| PCL-600 | 2000-3000 | 30 | 12-30 | 2*30 | 5.6 | 2800*Φ1500*2030 |
| PCL-750 | 1500-2500 | 35 | 25-55 | 2*45 | 7.3 | 3300*Φ1800*2440 |
| PCL-900A | 1200-2000 | 40 | 55-100 | 2*55 | 12.1 | 3750*Φ2120*2660 |
| PCL-900B | 1000-1450 | 40 | 65-130 | 2*75 | 13.6 | 3750*Φ2300*2090 |
| PCL-1050 | 1000-1700 | 45 | 100-160 | 2*(90-110) | 16.9 | 4480*Φ2450*2906 |
| PCL-1250 | 850-1450 | 45 | 160-300 | 2*(132-180) | 22 | 4563*Φ2650*3716 |
| PCL-1350 | 800-1193 | 50 | 200-360 | 2*(180-220) | 26 | 5340*Φ2940*3650 |
| Model | HXVSI-7611 | HXVSI-8518 | HXVSI-9526 | HXVSI-1140 | HXVSI-1145 | HXVSI-1150 | |
| Handling Capacity(t/h) | Waterfall and Central Feed | 120-180 | 200-260 | 300-380 | 450-520 | 500-610 | 520-650 |
| Whole Center Feed | 60-90 | 100-130 | 150-190 | 225-260 | 245-355 | 255-365 | |
| Maximum Feed Size(mm) | Soft Material | 35 | 40 | 45 | 50 | 50 | 50 |
| Hard Material | 30 | 35 | 40 | 40 | 45 | 45 | |
| Speed(r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1150-1300 | 1150-1300 | |
| Double Motor Power(kw) | 4P 110kw | 4P 180kw | 4P 264kw | 4P 400kw | 4P 400kw | 4P 500kw | |
| Shape Size(L*W*H)(mm) | 3700*2150*2100 | 4140*2280*2425 | 4560*2447*2778 | 5100*2700*3300 | 5500*2700*3300 | 5500*2700*3300 | |
