2400mm Long Wall Kraft Paper Machine, Cardboard Paper Machine, Corrugated Paper Machine

2400mm long wall kraft paper machine, cardboard paper machine, corrugated paper machine

Main equipment structure:

A, garden network department: Φ 1500 mm x 2850 mm stainless steel mesh cage three Φ 450 mm x 2850 mm, coucher three Φ roll back a 4500 mm x 4500 mm, rubber shore hardness 380 + 2. Pneumatic pressure device.

Press section: Φ stone roller a 600 mm x 600 mm, 550 mm * 2850 mm Φ rubber roller, a group with a scraper transmission department with 500 reducer.

Three, dry department: Φ dryer two 2500 mm x 2500 mm, dryer Φ 1500 mm x 2850 mm three, arrangement: 1 + 1 + 3 Φ 550 mm x 2850 mm roller two, pneumatic pressure device, rubber shore hardness 902 + 2, three sets of cylinder with network devices.

Paper roll section: cylinder paper roll machine.

Transmission and control department: ac frequency control, step drive, full digital closed loop control system. The processing standards of all parts shall be made in accordance with the standards prescribed by the machinery bureau of the ministry of light industry of the People's Republic of China for papermaking and pulping equipment.

Technical parameters:

Copied varieties: kraft paper; Cardboard paper, veneer cardboard paper.

Raw material: waste paper

Copied gram weight: 80 -- 350g/m2;

Clear paper width: 2400mm

Network width: 2850mm

Production capacity: 40-55t /D;

Rail distance: 3200mm;

Transmission mode: ac frequency control, step transmission;

Working rate: 80-120m/min

Model design: square box frame, cast iron

Our company mainly produces: 787, 1092, 1575, 1760, 1880, 2364, 2400, 2640, 2880, 3150, 3200, 3400, 3800, 4000, 4400 series paper machines. There are round network, long network, folding network and other types of paper machines and supporting pulping equipment, water treatment equipment.
