Model 2400 40-55t /D Wall Kraft Paper Machine, Cardboard Paper Machine, Corrugated Paper Machine

Model 2400 multi-cylinder multi-net wall kraft paper machine, paper wrapping machine, cardboard paper machine, corrugated paper machine

Technical parameters:

Copied varieties: kraft paper; Case board paper, corrugated paper, veneer board paper.

Raw material: waste paper

Copied gram weight: 80 -- 350g/m2;

Clear paper width: 2400mm

Network width: 2850mm

Production capacity: 40-55t /D;

Rail distance: 3200mm;

Transmission mode: ac frequency control, step transmission;

Working rate: 80-120m/min

Model design: square box frame, cast iron

Transmission and control department: ac frequency control, step drive, full digital closed loop control system. The processing standard of each component is according to the country

The paper and pulp equipment of the machinery bureau of the ministry of light industry shall be made according to the standards, and the shaft head shall be combined with hot pressing and double-row bearing design.

     Our factory is a high-tech enterprise which integrates the production and R&D of new-type papermaking machinery and pulping equipment. The main business now is: 787-1092-1575-1760-1880-2100-2400-2640-2880-3200-3600-4000-4750 single-cylinder, double-cylinder, multi-cylinder, long-net papermaking machine, circular net papermaking machine, cow Pulp and paper machine, culture paper machine, Xuan paper machine, carton hanging paper machine, packing corrugated paper machine, and small paper machine for small paper mills and family workshops, small environmental protection paper machine, toilet paper machine, burning paper machine, artillery paper machine, fire paper machine, yellow paper machine, etc. Various types of paper machines.

      Our factory has a complete set of pulping equipment: Dutch, Knife-Roller beater, high and low concentration hydraulic pulper, energy-saving pulper, high frequency vibrating screen, vacuum pump, pulp pump, pulp mixer, bamboo roughing mill, propeller, centrifugal screen, desander, processing various rolls and auxiliary equipment (toilet paper rewinder, punching pressure) Flower machine, toilet paper, burning paper cutting machine, etc. Papermaking equipment, calender, rewinder and paper cutter.

       Our factory is specialized in producing papermaking equipment, equipment in continuous updating to improve quality, established so far business sales have spread to Hebei, Henan, Hunan, Hubei, Shandong, Jiangsu, Jiangxi, Zhejiang, Fujian, Guangdong, Guangxi, Heilongjiang and other provinces and cities in Uzbekistan, Russia, Kyrgyzstan, Hasa Kistan is a foreign country.
