Tri-Shield CATV 75 Ohm Coaxial Cable,Copper Clad Steel RG11, RG cable for Close Circuit Television c

Brand Name	Libo		Place of Origin	China
Model Number	RG11 tri-shield0.16x128 90% coverage

Delivery Time:Within 10 days
Certification:CE, ISO9000,ISO14001,RoSH,Certificate of Network access of Broadcast equipment, State Administration

Tri-Shield CATV 75 Ohm Coaxial Cable,Copper Clad Steel RG11, RG cable for Close Circuit Television cable

Center conductor:

14AWG copper clad steel

Nominal diameter: 0.06405inches(1.625mm)±0.015(0.00065)

Dielectric:

Gas expanded polyethylene

Nominal diameter over dielectric: 0.28 inches(7.11mm)

Product description:

21% conductivity copper clad steel (21%CCS).Dielectric core is insulating grade virgin polyethylene. Bonded laminated aluminum tape, 60% braiding coverage, PVC jacket.

Shield:

1st shield: bonded aluminum tape.

2nd shield: 0.16 aluminum braid wire, 8ends x16 carry, pitch 20mm, 90% coverage.

Maximum ovality: 0.013inches (0.33)

3rd shield: normal aluminum foil.

Screening shield: ≧80dB

PVC Jacket:

Nominal diameter over jacket:0.400inches(10.16mm)±0.010inches(0.25mm)

Messenger version: 1.3mm zinc coated (galvanized) carbon steel wire.

Electrical properties:

Impedance : 75±3 ohms

Velocity of propagation: 82% nominal

Attenuation@ 68OF(20oC):

@Frequency MHZ	dB/100 meters(MAX.)
55	3.38
250	7.22
300	7.97
450	9.91
600	11.61
750	13.09
865	14.21
1000	15.32

Applications:

RG11 tri-shield 90% coverage cable is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.

Competitive Advantage:

RG11 tri-shield 60% coverage cable has outstanding anti-interference effectiveness and excellent transmission reliabilities. RG11 tri-shield cable is of low cost, and it is easy to install as well. Libo cable was established in 1994, it is subsidiary of Libo group which is one of the 500 largest private enterprises in China. Libo cable has a stable workforce and engineering team, lead-time of 40’FCL is about 7 days. Libo cable is equipped with a Provincial-level Research and Development Center, we offer OEM and ODM services.
