Product Details
| Brand Name | Libo | Place of Origin | China | |
| Model Number | RG500 cable |
Product Description
Certification:CE, ISO9000,ISO14001,RoSH,Certificate of Network access of Broadcast equipment, State Administration
Internation Standard 75 ohm RG500 Coaxial Cable, Tinned Copper Wire Braid Trunk Cable with IEC61196-1 Standard
Product description:
RG500 braiding cable is produced according IEC61196-1 international standard. Inner conductor is bare solid copper. Dielectric core is insulating grade virgin polyethylene. The 1st shield is two aluminum foils laminated to a strength member and a bonding resin on one side, the second shield is 82%?Tinned copper wire braid; PE for outer sheath.
Center conductor:
Bare copper
Nominal diameter: 2.77mm
Dielectric:
Gas expanded polyethylene
Nominal diameter over dielectric: 11.43mm
Shield:
1st shield: BAPA
2nd shield:?Tinned copper wire braid, 0.16x 8ends x24 carry, pitch is 38mm, 82% coverage.
PE Jacket:
Nominal diameter over jacket: 14.43mm
Electrical properties:
Impedance : 75±3 ohms
Velocity of propagation: 86% nominal
V.S.W.R: 1.25
Attenuation@ 68OF(20oC):
|
@Frequency MHZ |
dB/100 meters(MAX.) |
|
10 |
0.90 |
|
50 |
1.90 |
|
150 |
1.86 |
|
250 |
3.39 |
|
350 |
4.38 |
|
450 |
5.20 |
|
750 |
5.82 |
|
864 |
7.29 |
|
1000 |
8.40 |
Applications:
CATV-community antenna television ?CCTV-closed-circuit television ?DBS-direct broadcasting satellite
Competitive Advantage:
